Buy Dehner Elektronik SPE 320-05 SMPSU 5 V DC 60 A 320 W

Power supply unit in rectangular format with ventilation slots and fan. Suitable for industrial applications. CE-certified, Model BPE-320-05.

Fast track dispatch on Wed, 23 Sep

1 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 105.03 / piece)

€ 130.25

-19 %

€ 105.03

plus VAT.

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Dehner Elektronik SPE 320-05 SunPower 320 Watt

Output 5 V DC / 60 A
Power 320 W
Screw terminal

Technical specifications

Product type: SMPSU

Input voltage (max.): 264 V AC
375 V DC

Max. output current: 60 A

Output current (max.) - rounded: 60 A

Min. input voltage: 85 V AC
120 V DC

Dim: (L x W x H) 212 x 115 x 30 mm

Output voltage (max.): 5 V DC

Connection: Screw terminal

: 320 W

No. of outputs: 1 x

Type: closed

Operating temperature (max.): 50 °C

Max. operating temperature (derating): 70 °C

Operating temperature (min.): -30 °C

Weight: 720 g

PSU features: Regulated

Type: Switched PSU

Width: 115 mm

Height: 30 mm

Length: 212 mm

Type: SPE 320-05

MTBF: 176000 h

PFC: Yes

Max. temperature: 85 °C

Min. temperature: -40 °C

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2139996 Dehner Elektronik SPE 320-05 SMPSU 5 V DC 60 A 320 W

Warranty Terms

Warranty Terms 2139996 Dehner Elektronik SPE 320-05 SMPSU 5 V DC 60 A 320 W

Description

With the SPE series, Sunpower is expanding its portfolio to meet the needs of the music, film and advertising industries, recording studios, music producers and artists. Other applications include applications for the PA of arenas, exhibition halls and large events, electronic devices for content creation and consumer electronics.

By being approved to the EN 62368-1 standard to be applied from 21 June 2019, developers can plan the SPE series power supplies for applications of all kinds in a future-proof manner. The low design of only 30mm makes it also suitable for 1U racks.

The IEC/EN 62368-1 standard summarizes the previous safety standards for IT applications (IEC/EN 60950-1) and for audio/video applications (IEC/EN 60065). The new standard covers security aspects for IT and telecommunications applications as well as for audio and video applications.

This text is machine translated.
