TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 59.99 / piece)
€ 59.99
incl. VAT
Only 9 Piece(s) available
Highlights & Details
TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
- 5 V DC
- 3000 mA
- 15 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
Power supply unit
- Input voltage (max.)
264 V AC
- Max. output current
3 A
- Output current (max.) - rounded
3 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 96 x 54 x 24 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
15 W
- No. of outputs
1 x
- Output voltage 1
5 V DC
- Output current 1
3000 mA
- Type
closed
- Weight
162 g
- Type
Synchronised
- Width
54 mm
- Height
24 mm
- Length
96 mm
- Type
TMP 15105C
- MTBF
280000 h
15 W
- Connection
Screw terminals
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 511970 TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
Datasheet 511970 TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
User & Safety Instructions
User & Safety Instructions 511970 TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
Warranty Terms
Warranty Terms 511970 TracoPower TMP 15105C Power supply unit 5 V DC 3 A 15 W
Description
Shed power supply module for chassis mounting with screw terminals. The module is designed for AC and DC capable operation
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
