TracoPower TMP 15148C SMPSU 48 V DC 0.31 A 15 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 5
Total (€ 55.99 / piece)
€ 55.99
incl. VAT
14-day return policy included
Highlights & Details
TracoPower TMP 15148C SMPSU 48 V DC 0.31 A 15 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
0.31 A
- Output current (max.) - rounded
310 mA
- Min. input voltage
90 V AC
- Dim
(L x W x H) 23.3 x 54.0 x 96.0 mm
- Output voltage (max.)
48 V DC
- Connection
Screw terminal
15 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-25 °C
- Weight
162 g
- Type
Synchronised
- Width
54.0 mm
- Height
96.0 mm
- Length
23.3 mm
- Type
TMP 15148C
- Connection
Soldering pins
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371523 TracoPower TMP 15148C SMPSU 48 V DC 0.31 A 15 W
User & Safety Instructions
User & Safety Instructions 3371523 TracoPower TMP 15148C SMPSU 48 V DC 0.31 A 15 W
Warranty Terms
Warranty Terms 3371523 TracoPower TMP 15148C SMPSU 48 V DC 0.31 A 15 W
Description
Shed power supply module for PCB mounting with solder pins for chassis mounting with screw terminals. The module is designed for AC and DC capable operation TMPM version with ultra-compact design.
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
