Name: Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 300 W 1 pc(s)
Brand: Ehmann
SKU: 702392
Availability: InStock

A black, rectangular electronic device with a sliding control and dotted details, possibly a control unit.

Yellow sign with white circle: gear symbol with spanner, '5 Years', underneath 'REPAIR SERVICE'.

1/2

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

9 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 48.40 / piece)

€ 48.40

incl. VAT

Only 9 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

NV-Halogen lamp-Phase Section-Cord Dimmer

Electronic Short Circuit Protection
Separate On/ Off Switch
Slider for hand and foot control

Technical specifications

Actuation: sliders and switches
Control: reverse phase control
Suitable for: 230 V halogen lamps, NV-Halogen lamps with electronic transformers

Product type: Pull dimmer

Factory colour: Black

Length: 130 mm

Width: 60 mm

Height: 35 mm

Dim: (L x W x H) 130 x 60 x 35 mm

Min. switching capacity: 20 W

Max. switching capacity: 300 W

Switching voltage: 230 V AC

Content: 1 pc(s)

Type: LUMEO MOBIL

Operating voltage: 230 V AC

Documents & Downloads

Datasheet

Datasheet 702392 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 300 W 1 pc(s)

User & Safety Instructions

User & Safety Instructions 702392 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 300 W 1 pc(s)

Description

Phase Section-Dimmer for low voltage halogen lamps (electronic transformers), tungsten-halogen lamps and small lamps. The device is free of hum and has an electronic short circuit protection. On the slider the desired brightness can be adjusted. Using a separate device to switch it on and off without changing the basic brightness. The orientation light on the device makes it easier to locate in the dark. With the various ways to connect the cord dimmer can be used alternatively as an intermediate or terminal .
