Name: Extech EC510 Conductivity tester Conductivity, Temperature, pH, TDS, Salt content
Brand: Extech
SKU: 3088668
Availability: InStock

Portable pH and conductivity meter in green design, with test liquids and accessories in a black carry case.

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 289.00 / piece)

€ 289.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Salt content: 100 - 999 ppm
Protection class IP57

Product type: Conductivity tester

Reading type: Conductivity
Temperature
pH
TDS
Salt content

Display: Digital

Dim: (L x W x H) 36 x 41 x 186 mm

Weight: 110 g

Conductivity reading range: 0 - 199 µS

Conductivity reading range (max.): 199 µS

Conductivity reading range (min): 0 µS

TDS reading range: 0 - 99.9 ppm

TDS reading range (max.): 99.9 ppm

TDS reading range (min.): 0 ppm

Temperature reading range: -5 up to +90 °C

Temperature reading range (max.): +90 °C

Temperature reading range (min.): -5 °C

pH reading range: 0 - 14 pH

pH reading range (max.): 14 pH

pH reading range (min.): 0 pH

Width: 41 mm

Height: 186 mm

Length: 36 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3088668 Extech EC510 Conductivity tester Conductivity, Temperature, pH, TDS, Salt content

User & Safety Instructions

User & Safety Instructions 3088668 Extech EC510 Conductivity tester Conductivity, Temperature, pH, TDS, Salt content

Description

The EC510 is a conductivity test kit. The kit contains the EC500 meter, 3 calibration standards, 3 pH buffer bags plus flushing solution, 3 cups, batteries and carry case. Measures 5 parameters including conductivity, TDS, salinity, pH and temperature with one electrode. Analog bar graph shows trends. The memory stores up to 25 measured values. Adjustable conductivity/TDS ratio from 0.4 to 1.0; 0.5 fixed salt content ratio.

This text is machine translated.

Features

Measures 5 parameters including conductivity, TDS, salinity, pH and temperature with one electrode
9 measuring units: PH, µS/cm, MS/cm, ppm, ppt, mg/L, g/L, °C, °F
Analog bar graph shows trends
The memory stores up to 25 measured values
Adjustable conductivity/TDS ratio from 0.4 to 1.0; 0.5 fixed salt content ratio
The RENEW function warns the user when the electrode needs to be replaced

Scope of delivery

EC500-Meter
3 calibration standards
3 pH buffer bag plus rinsing solution
3 cups
Batteries
Carrying case
