Fluke FLK-393-IRR-PVLEAD Clamp meter Digital incl. solar irradiance meter CAT III 1500 V
EAN:
Part number:
Item no:
Number
Total (€ 1,315.13 / piece)
€ 1,315.13
plus VAT.
Only 3 Piece(s) available
Highlights & Details
FLK-393-IRR-PVLEAD
- CAT III 1500 V
Technical specifications
- Voltage reading range DC (min.)
600 V
- Product type
Clamp meter
- Voltage DC reading range (max.)
1500 V
- V AC reading range (min.)
600 V
- V AC reading range (max.)
1000 V
- A DC reading range (max.)
999 A
- A AC reading range (min.)
999 A
- Amperage reading range AC (max.)
2500 A
- Reading range - resistance
6000 Ω
- Reading range - capacity
1000 μ F
- Frequency reading range
5 to 500 Hz
- Basic accuracy
1 %
- Measurement type (details)
True RMS
Manufacturer's standards (no certificate)
- Reading category
CAT III 1500 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
FLK-393-IRR-PVLEAD
- Display
Digital
- Features
incl. solar irradiance meter
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2694121 Fluke FLK-393-IRR-PVLEAD Clamp meter Digital incl. solar irradiance meter CAT III 1500 V
Description
The true RMS AC/DC clamp-on ammeter 393 FC with safety in accordance with measurement category CAT III 1,500 V was developed for PV installation and maintenance engineers who work in applications with high DC voltages. Connect the measuring lines securely to the clamp-on ammeter to measure the voltage and current of individual panels or a series of panels in PV-systems. The PVLEAD1 test leads with MC4 connectors are used for regular testing and measurements and for troubleshooting PV solar modules. When using the PVLEAD3 SOLAR MC4 test leads, the power cables can remain connected during the measurements. This allows measurements to be made during operation. Use the IRR1-SOL irradiation meter to determine the solar radiation required to calculate the current voltage characteristic of the output power. Check if the panel or the series of panels is delivering the correct voltage.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Fluke 393 FC clip-on ammeter with safety specifications in accordance with CAT III 1500 VTest leads, CAT III safety rating, 1,500 V rated voltage, angled plugs with safety capsFlexible clip-on ammeter iFlex (sensor length 46 cm)Magnet strap TPAKPremium transport caseFLK-IRR1-SOL IRRADIATION METERFLK80PR-IRR External temperature sensor with suction cupC250 carrying case with shoulder strapMeasuring lead set Pomona PVLEAD1, MC4 auf 4 mmPomona PVLEAD3 test lead set with MC4 connectors
