Name: Fluke VRLA tester BT520 Reading range (battery testers) < 600 V Rechargeable, Battery 4489981
Brand: Fluke
SKU: 1499816
Availability: BackOrder

Yellow portable device with display: Resistance 2.64 mΩ, Voltage 13.21 VDC. Buttons for measurement settings and view.

A yellow digital multimeter displays '13.21 VDC' and has red and black test leads. It is being used to measure voltage.

Multimeter with black and red test leads. Ideal for measuring electrical voltage, current, and resistance.<br><br>Multimeter with black and red test leads. Perfect for measuring electrical voltage, current, and resistance.

A battery analyser displays '13.21 VDC' on the screen. The device is yellow and has several buttons and rotary switches.

1/5

EAN:

Part number:

Item no:

Dispatches on Mon 23 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 6,309.00 / piece)

€ 6,309.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Fluke BT520 Battery tester

For storage batteries and battery banks
Maintenance, troubleshooting and performance testing
Incl. intelligent probe BTL20

Technical specifications

Display: LCD

Product type: VRLA tester

Compatible with: PbCa
SLA
Lead acid
Lead silicon
VRLA AGM
Lithium

Reading range: < 600 V

Cell type: Rechargeable
Battery

Features: incl. battery

Power supply: Li-ion rechargeable battery

Width: 103 mm

Height: 220 mm

Depth: 58 mm

Weight: 850 g

Interfaces: USB

Dim: (W x H x D) 103 x 220 x 58 mm

Type: BT520

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1499816 Fluke VRLA tester BT520 Reading range (battery testers) < 600 V Rechargeable, Battery 4489981

Description

The new battery tester Fluke 500 series are ideal for the maintenance, troubleshooting and performance testing of individual storage batteries and battery banks used in critical applications with battery backup. The intuitive user interface, compact design and rugged construction ensure optimum performance and reliable test results.
The battery tester Fluke 500 series cover a wide range of battery test functions of DC and resistance tests to complete state tests using an automated train functional testing and integrated into the measuring head infrared temperature measurement system. The battery tester 500 series have been specifically designed for measurements on stationary batteries, including gel batteries, AGM (Absorbent Glass Mat) and open cells with float.

Features

battery voltage
While the internal resistance test, the device measures the voltage to be tested batteries.
discharge
In the discharge mode, the voltage of each battery during discharge or loading test several times during a user-defined interval is detected. The user can calculate the time it takes to reach the cutoff voltage of the battery. On the basis of this period, the capacity loss can be determined.
measuring the voltage ripple
Measures the unwanted AC component of the rectified voltage in the Gleichstromlade- and inverter circuits. Makes it possible to measure AC components to DC charging circuits and to recognize a major cause of power loss and aging of batteries and batteries.
Measuring mode and automated test sequence
The measuring instruments used for the rapid measurement mode or troubleshooting. In this mode, you can store the measured values in a time sequence and read. The automated test sequence is intended for maintenance work at several power systems and battery strings. Before the execution of a task, the user can configure a profile for data management and report generation.
Threshold and Warning
The user can configure a maximum of 10 sets of thresholds based on which it can receive a PASS, warning or FAIL displayed after each measurement.
measurement of the cell connection resistance and data management
Measures the resistance of the cells connections of a battery string. After completing the measurements, the Fluke Battery Management Software version 1.0.69 can generate a report on the cell connection resistance of a battery string, or the history of the data, now.
Auto Hold
When the auto-hold function, a measured value is detected, if it is 1 second stable. After that, the measured value at the start of a new measurement is released.
Auto Save
When the auto save function measured values are automatically stored in the internal memory after a car hold measurement value has been detected.
Fluke battery management software
Used for easy import of data from the device to a PC. The measured data and the data of the profiles of batteries are stored using the management software and archived and can be used for comparison and trend analysis. All measurement data profiles and the analysis data can be used to easily create reports.
Comprehensive logging
All measured values are automatically recorded during the test and can be reviewed on the meter before they are downloaded for analysis and documentation.
Streamlined interface
Thanks to the menu-driven setup, you always capture the right data.
Operating time
The lithium-ion battery with 7.4 V 3000 mAh allows eight hours of continuous operation.
USB
Used to quickly download data for use by the included supplied application software for data analysis and report management.
Highest safety rating
Measurement Category CAT III 600 V, max. 1000 V DC for safely around the power from battery packs.
BTL20
Intelligent measuring probe with long and short measuring tip extensions and integrated LCD display and speakers for visual and audible output.
Large padded carrying case.

Scope of delivery

Battery analyzer
4-wire test pin (set)
BTL10 Basic Test Lead (set)
TL175 TwistGuard™ Test Leads with adapter
BTL20 Intelligent Test Probe Set
with extender (no temperature sensor)
BP500 lithium-ion battery
BC500 AC charger
Mini-USB cable
Shoulder strap
Belt strap
Magnetic hanging strap
FlukeView® Battery Management Software
Soft carrying case
Spare fuses (2)
Battery tags
Zero Ohm Calibration Resistor

Hints

This text is machine translated.
