Name: Greisinger GES 500 Needle probe -65 up to 550 °C Sensor type K
Brand: Greisinger
SKU: 649993
Availability: InStock

Tip of a silver-coloured, metallic tool with a conical end, possibly a chisel or drift tool.

Drawing of a voltage tester with handle, screwdriver tip and cable with plug, overall dimensions approximately 187 mm.

1/2

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 5 Nov

6 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 63.99 / piece)

€ 63.99

incl. VAT

Only 6 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Greisinger insertion probe for soft plastic media GES 500

Sensor type K
-65 up to 550 °C
Heating element connector

Technical specifications

Probe NiCr-Ni, type K
Measuring range: -65 to +550 °C
With thermal voltage-free flat plug

Product type: Needle probe

Sensor type: K

Pick-up time (details): 5 s

Temperature reading range (min.): -65 °C

Temperature reading range (max.): 550 °C

Dim: (Ø x L) 3 mm x 265 mm

Probe length: 130 mm

: Manufacturer's standards (no certificate)

Connector: Heating element connector

Cable length: 1 m

Temperature reading range: -65 up to 550 °C

Temperature accuracy: ± 1,5 °C

Compatible with (details): Suitable for all Greisinger temperature measuring devices with connection for type K-sensor (NiCr-Ni) with mini flat plug

Width: 3 mm

Length: 265 mm

(Ø): 3 mm

Connection: Heating element connector

Documents & Downloads

Datasheet

Datasheet 649993 Greisinger GES 500 Needle probe -65 up to 550 °C Sensor type K

User & Safety Instructions

User & Safety Instructions 649993 Greisinger GES 500 Needle probe -65 up to 550 °C Sensor type K

Description

Penetration sensor with handle for soft malleable materials. The sensor consists of a thin V4A tube with a diameter of 3 mm with needle shaped insertion tip. The connection to the measuring device is supplied via a 1 m long silicone cable with type K (NiCr-Ni) Mini flat plug. The robust plastic handle has a kink protection gland to protect the connection cable.

This text is machine translated.
