Hirschmann Test & Measurement BIL 20 Au vi Jack socket Socket, vertical vertical Pin diameter: 4 mm Violet 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 1.92
10
7% = € 0.14
€ 1.78
25
10% = € 0.20
€ 1.72
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 1.92 / piece)
€
Highlights & Details
Panel socket BIL 20 Au
- 4 mm
- gold-plated
Technical specifications
- Nominal current
32 A
- Nominal current - rounded value
32 A
- Manufacturer part #
930176709
- Type
BIL 20 Au vi
- Content
1 pc(s)
- Dim
- Factory colour
Violet
- Connection
Soldering
- Insulation type
Partially insulated
- Material (details)
Insulation: Duroplast · Contact: brass, gold-plated
- Nominal voltage
60 V DC
- Pin Ø
4 mm
- Connector type
Socket, vertical vertical
- Insulation material
Duroplast
- Nominal voltage (details)
60 V DC
- Nominal current (details)
32 A
- Connection
Soldering
- Contact material
Diecast zinc
- Temperature range
-25 to +85 °C
- RoHS-compliant
Yes
- Product type
Jack socket
Variants(All information is without VAT, plus shipping costs)
Factory colour
Hirschmann Test & Measurement BIL 20 Au vi Jack socket Socket, vertical vertical Pin diameter: 4 mm Violet 1 pc(s)
This article
Violet
Minimum order quantity: 1
Multiple: 1
€ 1.92*
Hirschmann Test & Measurement BIL 20 Au Jack socket Socket, vertical vertical Pin diameter: 4 mm Black 1 pc(s)
Black
Minimum order quantity: 1
Multiple: 1
€ 2.34*
Hirschmann Test & Measurement BIL 20 Au Jack socket Socket, vertical vertical Pin diameter: 4 mm Red 1 pc(s)
Red
Minimum order quantity: 1
Multiple: 1
€ 4.03*
Hirschmann Test & Measurement BIL 20 Au Jack socket Socket, vertical vertical Pin diameter: 4 mm Blue 1 pc(s)
Blue
Minimum order quantity: 1
Multiple: 1
€ 2.34*
Hirschmann Test & Measurement BIL 20 Au Jack socket Socket, vertical vertical Pin diameter: 4 mm Yellow 1 pc(s)
Yellow
Minimum order quantity: 1
Multiple: 1
€ 2.34*
Jack socket Socket, vertical vertical Pin diameter: 4 mm Green Hirschmann Test & Measurement BIL 20 Au gn 1 pc(s)
Green
Minimum order quantity: 1
Multiple: 1
€ 1.67*
Hirschmann Test & Measurement BIL 20 Au gr Jack socket Socket, vertical vertical Pin diameter: 4 mm Grey 1 pc(s)
Grey
Minimum order quantity: 1
Multiple: 1
€ 2.34*
Documents & Downloads
Datasheet
Datasheet 734747 Hirschmann Test & Measurement BIL 20 Au vi Jack socket Socket, vertical vertical Pin diameter: 4 mm Violet 1 pc(s)
User & Safety Instructions
User & Safety Instructions 734747 Hirschmann Test & Measurement BIL 20 Au vi Jack socket Socket, vertical vertical Pin diameter: 4 mm Violet 1 pc(s)
Description
Bushing with insulated top and installation around equipment chasis and switchboard up to 2mm wall strength.
