Name: Hirschmann Test & Measurement PMS SKS Electronic Safety terminal set 4 mm jack connector , 2 mm jack connector , 0.64 mm
Brand: Hirschmann Test & Measurement
SKU: 122929
Availability: InStock

'An opened tool case with various electronic accessories, such as cables, clamps and measuring leads, arranged in compartments.'

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 259.00 / piece)

€ 259.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Service case "Electronic"

For development, service, training and more

Technical specifications

Product type: Safety terminal set

Connection: 4 mm jack connector
2 mm jack connector
0.64 mm jack connector

Max. clamping range: 30 mm

Factory colour: Black
Red
Yellow
Green

Nominal voltage: 1000 V

Reading category: CAT III 1000 V

Jack diameter: 0.64 mm

Content: 1 Set

Nominal current: 25 A

Type: PMS SKS Electronic

Documents & Downloads

Datasheet

Datasheet 122929 Hirschmann Test & Measurement PMS SKS Electronic Safety terminal set 4 mm jack connector , 2 mm jack connector , 0.64 mm

User & Safety Instructions

User & Safety Instructions 122929 Hirschmann Test & Measurement PMS SKS Electronic Safety terminal set 4 mm jack connector , 2 mm jack connector , 0.64 mm

Description

Service case with high-quality measuring accessories

Features

Safety test probes with spring-loaded stainless steel tip for 1000V CAT II
Miniature probe with spring probe with constant pressure
Miniature terminal probes with rotating gripping pliers
Self-holding SMD test clip 0.64 mm pin connector
Miniature terminal probes with gold plated terminal hooks, 7 colours
Adapter plug 2 mm on 4 mm system
Contact-protected Miniature alligator clips up to 6 mm nut diameter
Contact-protected, wide opening alligator clips up to 30 mm nut diameter
Two foot positioned for accurate positioning of probe tips
Adapter measuring leads 4 mm plug stackable on 0.64 mm socket, black, red, length 100 cm
Black miniature testing leads, red with two 0.64 mm sockets, black, red L = 25 cm
Contact-proof measuring leads for 1000V CAT III with stackable plugs, black, red, green / yellow, length 50 cm
BNC adapter cable on 2 x 0.64 mm rectangular rod, black, red
High ohmic passive probe, 150 MHz separate bandwidth with changeable spring tip.

Scope of delivery

Service case
2 x 4 mm test probes
8 x 0.64 mm miniature test probes
2 x 0.64 mm terminal test probes
1x 0.64 mm Micro SMD-Clip
2 x Adapter plug (2 mm on 4 mm)
3 x 4 mm alligator clips
1 x two base positioned
2 x Adapter measuring leads
2 x 0.64 mm measuring leads
3 x 4 mm measuring leads
1 x BNC Adapter cord
