Jauch Quartz LI-NCM14500J Non-standard battery (rechargeable) 14500 Cable Li-ion 3.6 V 850 mAh 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 18.99 / piece)
€ 18.99
incl. VAT
14-day return policy included
Highlights & Details
Li-ion battery
- High energy density
- With protective electronics
- Lightweight
- Over- and deep discharge protection
Technical specifications
- Cable length: 45 mm.
- Size
14500
- Product type
Non-standard battery (rechargeable)
- Technology
Li-ion
- Dim
(Ø x H) 15 mm x 53 mm
- Voltage
3.6 V
- Capacity (mAh, Ah)
850 mAh
- Special-purpose battery features
Cable
- Max. charge voltage
4.2 V
- Max. charging current
850 mA
- Terminal voltage
2.75 V
- Discharge current (max.)
1.7 A
- Continuous discharge
0.17 A
- Min. temperature
-20 °C
- Max. temperature
+60 °C
- Height
53 mm
- (Ø)
15 mm
- Weight
30 g
- Content
1 pc(s)
- Type
LI-NCM14500J
- Rechargeable
Yes
- Integrated surge protection
Yes
Documents & Downloads
Datasheet
Datasheet 2141953 Jauch Quartz LI-NCM14500J Non-standard battery (rechargeable) 14500 Cable Li-ion 3.6 V 850 mAh 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2141953 Jauch Quartz LI-NCM14500J Non-standard battery (rechargeable) 14500 Cable Li-ion 3.6 V 850 mAh 1 pc(s)
Information
Test Summary Report 2141953 Jauch Quartz LI-NCM14500J Non-standard battery (rechargeable) 14500 Cable Li-ion 3.6 V 850 mAh 1 pc(s)
Description
In the accumulator, lithium ions (Li+) can move freely through the electrolyte between the two electrodes, from which the name of the accumulator is derived. Lithium-ion cells are characterized by a high energy density. The useful life is several years. Lithium-ion cells react critically to overcharging. Therefore, the battery is equipped with a protective electronics, which protects against overcharging.
Lithium is a chemical element and the lightest metal. It offers two advantages for the use in rechargeable batteries: It has the greatest negative voltage potential, and it is also the lightest element in fixed form.
This text is machine translated.
Lithium is a chemical element and the lightest metal. It offers two advantages for the use in rechargeable batteries: It has the greatest negative voltage potential, and it is also the lightest element in fixed form.
This text is machine translated.
