Image similar
Image similar
JST Socket housing cable Total number of pins 7 Contact spacing: 2 mm PARP-07V 1 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
CS
2 mm
Total number of pins
7
Datasheet (PDF)
580 Piece(s)
Sales and shipping:
Number
Minimum order quantity: 30
Total (€ 0.07 / piece)
€
Highlights & Details
Multi-pin connector – pitch 2.0 mm, PHD series
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 7
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Features
+ latch
- CS
2 mm
- Pins per row
7
- Total number of pins
7
- Content
1 pc(s)
- Manufacturer part #
PARP-07V
- Industrial packaging
No
- RoHS-compliant
Yes
- Type
PARP-07V
- Material (details)
PA 66 UL94V-0
- Nominal voltage (details)
250 V AC
- Nominal current (details)
3 A
- Cross section
0.08 - 0.33 mm²
- Connection
Crimp
Documents & Downloads
Datasheet
Datasheet 1426244 JST Socket housing cable Total number of pins 7 Contact spacing: 2 mm PARP-07V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1426244 JST Socket housing cable Total number of pins 7 Contact spacing: 2 mm PARP-07V 1 pc(s)
Description
2-row, detachable connection of cable to PCB. The catch bar casing allows an audible click when plugging in. A circular trough at the pin header ensures reverse voltage protection. Can be easily soldered thanks to pre-tinned pin header.
