Kendrion Pressure regulator 50.880.00.80.10 M5 Enclosure material Brass Sealant NBR 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 96.63 / piece)
€ 96.63
plus VAT.
Technical specifications
- M5 connection
- Pressure range 10 bar
- Pressure range: Up to 8 bar
- Medium: Non-aggressive media
- Operating medium
Non-aggressive media
- Type
50.880.00.80.10
- Product type
Pressure regulator
- Enclosure material
Brass
- Connection
M5
- Max. operating pressure
10 bar
- Operating temperature
0 °C (min)
- Min. operating temperature
0 °C
- Manufacturer part #
50.880.00.80.10
- Size
Mini
- Sealant
NBR
- Medium
Inert substances
- Control pressure (max.)
8 bar
- Max. ambient temperature
+60 °C
- Min. ambient temperature
0 °C
Documents & Downloads
Datasheet
Datasheet 3168395 Kendrion Pressure regulator 50.880.00.80.10 M5 Enclosure material Brass Sealant NBR 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3168395 Kendrion Pressure regulator 50.880.00.80.10 M5 Enclosure material Brass Sealant NBR 1 pc(s)
Description
Miniature pressure regulator with M 5 thread connection type: 50.880.00.80.00 pressure range: Max. 8 bar, material Housing: Brass galvanized, nickel-plated, membrane: NBR, fabric reinforced, Medium: Non-aggressive medium, connection type: M 5, ambient temperature: 0 to +60 °C, without secondary ventilation (SE).
This text is machine translated.
This text is machine translated.
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
