KOPOS KSK 100 PO Junction box Halogen-free (W x H x D) 101 x 101 x 46.5 mm 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 38.65 / piece)
€ 38.65
plus VAT.
Highlights & Details
Junction box 100 IP66 orange with function receives
- IP66 protection rating
- Halogen-free
- Color: orange (RAL 2004)
Technical specifications
- Product type
Junction box
- Features
Halogen-free
- Mounting type
Surface-mount
- Type
With terminal strip
- Content
1 pc(s)
- Factory colour
Orange
- Dim
(W x H x D) 101 x 101 x 46.5 mm
- Width
101 mm
- Height
101 mm
- Depth
46.5 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1662807 KOPOS KSK 100 PO Junction box Halogen-free (W x H x D) 101 x 101 x 46.5 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1662807 KOPOS KSK 100 PO Junction box Halogen-free (W x H x D) 101 x 101 x 46.5 mm 1 pc(s)
Information
Information 1662807 KOPOS KSK 100 PO Junction box Halogen-free (W x H x D) 101 x 101 x 46.5 mm 1 pc(s)
Description
Suitable for installation that requires maintenance in case of a fire. Used exclusively for power cables with functional maintenance. The box contains a ceramic terminal with functional retention, it is suitable for 5 conductors with cross-section of 1.5 to 6 mm². The can is attached to the concrete with the attached anchor. The soft puncture membranes enable a simpleCable gland, with protection class IP 66. The cover is secured by the supplied stainless steel screws.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Junction box
- Stainless steel screws.
