Buy MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

A switched-mode power supply on a DIN rail. Inscription shows input of 67-264VDC and output of 12V at 10A. Manufacturer: MEAN WELL.

Datasheet (PDF)

Fast track dispatch on Mon, 28 Sep

107 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 63.86 / piece)

€ 63.86

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

MEANWELL DC/DC converter series DDR-120 for DIN rail Single Output Input voltage ratio: 2:1 Power: 120 W

For DIN rail mounting.
Can be used on DIN-rail TS-35/7.5 or 15 can be installed
Width of only 32 mm
2:1 input voltage range
150% peak load capacity
Regulated output voltage
Cooling by free air convection
Input/output insulation 4000 V
Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
This text is machine translated.

Technical specifications

Nominal input voltage: 24 V/DC

Product type: Rail mounted DC/DC converter (DIN)

Min. input voltage: 16.8 V DC

Output voltage: 24 V DC

Input voltage: 16,8-33.6 V DC

Input voltage (max.): 33.6 V DC

Max. output current: 5 A

Output current (max.) - rounded: 5 A

: 120 W

Output type (power supply units): Adjustable

Output voltage (nominal): 24 V DC

No. of outputs: 1 x

Connection: Clamp

Dim: (L x W x H) 32 x 102 x 125.2 mm

Weight: 510 g

Output voltage (max.): 28 V DC

Output voltage (min.): 24 V DC

Operating temperature (max.): +70 °C

Operating temperature (min.): -40 °C

Manufacturer part #: DDR-120B-24

Content: 1 pc(s)

MTBF: 214600 h

PSU features: DC-to-DC converter
Regulated
Adjustable voltage output

Width: 102 mm

Height: 125.2 mm

Length: 32 mm

Type: DDR-120B-24

Efficiency: 89.5 %

UKCA: yes

Variants(All information is without VAT, plus shipping costs)

Power

Input voltage (max.)

Output voltage (nominal)

Output voltage

Nominal input voltage

Output current (max.) - rounded

Min. input voltage

MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113475

This article

120 W

33.6 V DC

24 V DC

24 V/DC

5 A

16.8 V DC

MEAN WELL DDR-15G-12 Rail mounted DC/DC converter (DIN) 12 V DC 1.25 A 15 W No. of outputs:1 x Content 1 pc(s)

Item no:2113417

15 W

36 V DC

12 V DC

24 V/DC

1.25 A

9 V DC

MEAN WELL DDR-15G-3.3 Rail mounted DC/DC converter (DIN) 3.3 V DC 3.5 A 11.6 W No. of outputs:1 x Content 1 pc(s)

Item no:2113418

11.6 W

36 V DC

3.3 V DC

24 V/DC

3.5 A

9 V DC

MEAN WELL DDR-120A-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.1 A 100.8 W No. of outputs:1 x Content 1 pc(s)

Item no:2113420

100.8 W

18 V DC

48 V DC

12 V/DC

2.1 A

9 V DC

MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113421

120 W

67.2 V DC

48 V DC

48 V/DC

2.5 A

33.6 V DC

MEAN WELL DDR-120D-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113438

120 W

154 V DC

48 V DC

2.5 A

67.2 V DC

MEAN WELL DDR-15L-15 Rail mounted DC/DC converter (DIN) 15 V DC 1 A 15 W No. of outputs:1 x Content 1 pc(s)

Item no:2113473

15 W

75 V DC

15 V DC

48 V/DC

1 A

18 V DC

MEAN WELL DDR-15L-12 Rail mounted DC/DC converter (DIN) 12 V DC 1.25 A 15 W No. of outputs:1 x Content 1 pc(s)

Item no:2113476

15 W

75 V DC

12 V DC

48 V/DC

1.25 A

18 V DC

MEAN WELL DDR-15G-24 Rail mounted DC/DC converter (DIN) 24 V DC 0.63 A 15 W No. of outputs:1 x Content 1 pc(s)

Item no:2113495

15 W

36 V DC

24 V DC

24 V/DC

630 mA

9 V DC

MEAN WELL DDR-120D-12 Rail mounted DC/DC converter (DIN) 12 V DC 10 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113496

120 W

154 V DC

12 V DC

10 A

67.2 V DC

Documents & Downloads

Datasheet

Datasheet 2113475 MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2113475 MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Warranty Terms

Warranty Terms 2113475 MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Description

Features

Can be used on DIN-rail TS-35/7.5 or 15 can be installed
Width of only 32 mm
2:1 input voltage range
150% peak load capacity
Regulated output voltage
Cooling by free air convection
Input/output insulation 4000 V
Protection: short circuit, overload, over voltage, input polarity, input under voltage protection
