Müller KNX 24701 Room thermostat TS 31.12 knx
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Weidmüller TS 31.12 KNX white, room temperature controller
- Integrated room temperature control with touch-set point adjustment
- 2 independent temperature zones controlled via KNX
- Flexible sensor integration (up to 4 temperature values + external sensors)
- 3× 0–10 V analog outputs (e.g. for fan coils or actuators)
- 5 freely usable binary and analogue inputs
- RGB / RGBW / Tunable White light control
- KNX Secure and update enabled (future-proof)
- Clear ETS structure and easy commissioning
- Modern, flat surface-design (80 mm)
Technical specifications
- Built-in bus coupler
- LED status indicator
- Setpoint adjustment
- Series
KNX
Manufacturer-specific
- Used at
Indoors
IP20
- Operating voltage
21 V DC
32 V DC
0.5 W
- Data transfer (Smart Home)
Wired
- Channels
1
- Mounting type
Surface-mount
Wall
- Factory colour
Studio white (similar to RAL 9016)
- Width
80.5 mm
- Height
80.5 mm
- Depth
17 mm
- Dim
(W x H x D) 80.5 x 80.5 x 17 mm
- Data exchange
Bidirectional (bi)
- Hub
Not required, optional for remote access
- Weight
90 g
- Product type
Room thermostat
Documents & Downloads
Datasheet
Datasheet 3771301 Müller KNX 24701 Room thermostat TS 31.12 knx
User & Safety Instructions
User & Safety Instructions 3771301 Müller KNX 24701 Room thermostat TS 31.12 knx
Description
Enjoy maximum comfort and intelligent energy efficiency in your Smart home. The müller TS 31.12 KNX room temperature controller combines modern, flat design for wall mounting with highly developed KNX technology. In addition to the precise measurement and control of the room temperature, this smart all-rounder allows intuitive, manual adjustment of the desired temperature directly on site. Thanks to the integrated binary and analogue inputs the system can be flexibly expanded – for a perfectly matched feel-good climate in every room.
This text is machine translated.
This text is machine translated.
Features
- Recording of the room temperature
- Temperature sensor (measuring range 0...50 °C)
- Set temperature can be changed manually using the touch control panel
- 2 separate temperature controls via KNX
- Temperature control possible with up to 4 Sensor values
- 5 binary and analogue inputs (e.g. for connection of an external temperature sensor)
- 3x analogue outputs (0-10V)
- RGB, RGBW and Tunable White dimming function
- KNX secure
- Updateable
- Clearly structured ETS
- Easy handling and installation
- Modern, flat design for surface mounting [80 mm]
- Party function
Scope of delivery
- 1x Müller TS 31.12 KNX room temperature controller
- 1x integrated bus coupler
- 1x KNX terminal clamp (red/black)
- Mounting material (retaining ring and screws)
- Full operating and programming instructions (DE/EN)
