Name: Phoenix Contact 1725685 Screw terminal 0.50 mm² Number of pins 5 Green 250 pc(s)
Brand: Phoenix Contact
SKU: 774607
Price: 415 EUR
Availability: InStock

Green electrical connector with eight terminals and metal pins, used for circuit boards in electronic applications.

Image similar

Product type

Screw terminal

2.54 mm

Pins per row

Number of pins

Connection

Screw terminal

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Tue 17 Nov

14 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 250 pc(s))

Set(s)

Total (€ 1.66 / piece)

€ 415.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block MPT 0,5/ 5-2,54

Content 250 pc(s)

Technical specifications

Type: MPT 0,5/ 5-2,54

Product type: Screw terminal

Features: + extractor sleeve

CS: 2.54 mm

Pins per row: 5

Number of pins: 5

Series: MPT

Stripping length (max.): 4.50 mm

Connection: Screw terminal
Print

Nominal current: 6 A

Cross section (flexible) (min.): 0.14 mm²

Nominal current - rounded value: 6 A

Cross section (inflexible) (min.): 0.14 mm²

Cross section (flexible) (max.): 0.50 mm²

Cross section (inflexible) (max.): 0.50 mm²

AWG (min.): 26

Connector orientation: Parallel (to the PCB)

AWG max.: 20

Contact material: Tin plated

Factory colour: Green

Actuation direction: Perpendicular (to the PCB)

Manufacturer part #: 1725685

Industrial packaging: Yes

Content: 250 pc(s)

Nominal voltage: 160 V

Width: 15.00 mm

Height: 13.16 mm

Length: 6.20 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 774607 Phoenix Contact 1725685 Screw terminal 0.50 mm² Number of pins 5 Green 250 pc(s)

User & Safety Instructions

User & Safety Instructions 774607 Phoenix Contact 1725685 Screw terminal 0.50 mm² Number of pins 5 Green 250 pc(s)

Description

PCB terminal block, Nominal current: 6 A, Nom. voltage: 160 V, Pitch: 2.54 mm, Number of positions: 5, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green
