Phoenix Contact MINI MCR-2-I-I 2901998 Isolation amplifier 1 pc(s)
EAN:
Part number:
Item no:
Product type
Isolation amplifier
Type
MINI MCR-2-I-I
Dim
(L x W) 120.5 mm x 6.2 mm
Connection
Jack connector
Load
Output load current output: ≤ 600 Ω
Datasheet (PDF)
Total (€ 209.99 / piece)
€ 209.99
incl. VAT
14-day return policy included
Highlights & Details
3-way isolation amplifier
Technical specifications
- Transmission errors: 0.1% (of the final value).
- Type
MINI MCR-2-I-I
- Product type
Isolation amplifier
- Dim
(L x W) 120.5 mm x 6.2 mm
- Connection
Jack connector
- Load
Output load current output: ≤ 600 Ω
- Content
1 pc(s)
- Width
6.2 mm
- Length
120.5 mm
- Current consumption
25 mA at 24 V/DC) · 54 mA (12 V/DC)
- Max. ambient temperature
+85 °C
- Min. ambient temperature
-40 °C
- Operating voltage U(B)
9.6..30 V
IP20
- Operating voltage
24 V
- Frequency
30 Hz
- Connection
Screws
- Output signal
0 - 20 mA
4 - 20 mA
- Input signal
0 - 20 mA
4 - 20 mA
- Setting
Cannot be configured
- Supply voltage
9,6 - 30 V DC
- Input resistance
Current input: approx. 63 kΩ
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1199191 Phoenix Contact MINI MCR-2-I-I 2901998 Isolation amplifier 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1199191 Phoenix Contact MINI MCR-2-I-I 2901998 Isolation amplifier 1 pc(s)
Description
3-way isolation amplifier with pluggable connection technology for galvanic isolation, conversion, amplification and filtering of standardised signals.
This text is machine translated.
This text is machine translated.
Hints
Not configurable!
