Phoenix Contact 2864176 MINI MCR-SL-UI-2I-NC Configurable Signal Doubler Content: 1 pc(s)
EAN:
Part number:
Item no:
Input signal (current) (max.)
20 mA
Input signal (voltage) (max.)
10 V
Type
MINI MCR-SL-UI-2I-NC
Dim
(L x W x H) 102.5 x 6.2 x 93.1 mm
Connection
Screws
Datasheet (PDF)
Number
Total (€ 373.95 / piece)
€ 373.95
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Phoenix Contact 2864176 MINI MCR-SL-UI-2I-NC Configurable Signal Doubler Content: 1 pc(s)
- MINI Analog
- This text is machine translated.
Technical specifications
- Transmission errors: ≤ 0.2% (of the final value).
- Type
MINI MCR-SL-UI-2I-NC
- Input signal (current) (max.)
20 mA
- Input signal (voltage) (max.)
10 V
- Dim
(L x W x H) 102.5 x 6.2 x 93.1 mm
- Connection
Screws
- Output (current)
2 x 0 - 20 mA / 2 x 4 - 20 mA
- Load
≤ 250 Ω (with 20 mA)
- Input signal (voltage)
0 - 10 V / 1 - 5 V
- Input signal (current)
0 - 20 mA / 4 - 20 mA
- Input resistance
100 kΩ
- Content
1 pc(s)
- Width
6.2 mm
- Height
93.1 mm
- Length
102.5 mm
- Current consumption
< 25 mA (power output with 24 V DC incl. Last)
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-20 °C
- Supply voltage (num.)
24 V DC
- Type
MINI MCR-SL-UI-2I-NC
- Connection
Screws
- Output signal
2x 0 mA - 20 mA / 2x 4 mA - 20 mA
- Input signal
0 - 10 V/1 - 5 V/0 - 20 mA, 4 - 20 MA mA
- Supply voltage
19,2 - 30 V DC
- Input resistance
ca. 100 kΩ
Snap mounting support rail
6.2
93.1 mm
101.2 mm
0.6 W
-20-60 °C
Screw connection
IP20
None
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 740556 Phoenix Contact 2864176 MINI MCR-SL-UI-2I-NC Configurable Signal Doubler Content: 1 pc(s)
User & Safety Instructions
User & Safety Instructions 740556 Phoenix Contact 2864176 MINI MCR-SL-UI-2I-NC Configurable Signal Doubler Content: 1 pc(s)
Description
4-way signal doubler for galvanic separation and duplication of duplication of analogue signals.
Hints
Not pre-configured !
