PTR Hartmann 50840020201D Screw terminal 4.00 mm² Number of pins 2 Green 1 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
6.35 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Number
Total (€ 0.22 / piece)
€ 0.22
plus VAT.
14-day return policy included
Highlights & Details
Screw terminal block
Our service for you
Technical specifications
- Type
AKZ840/2-6.35-V
- Product type
Screw terminal
- Features
+ lifter
- CS
6.35 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
AKZ840
- Min. stripping length
7 mm
- Stripping length (max.)
7 mm
- Connection
Screw terminal
Print
- Nominal current
30 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
30 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
28
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Brass
- Factory colour
Green
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
50840020201D
- Content
1 pc(s)
- Nominal voltage
300 V
- Width
25.90 mm
- Height
13.30 mm
- Length
12.50 mm
