HF generator DSG836A

9 kHz to 3.6 GHz bandwidth
Frequency resolution 1 Hz, incl. pre-amplifier
Up to -135 dBm DANL
Incl. IQ modulation integrated!

Technical specifications

Frequency range: 9 kHz - 3.6 GHz

Frequency range (sine): 9 kHz - 3.6 GHz

Internal modulation: Am, FM, Phase, Pulse, IQ modulation

Dim: (W x H) 262 mm x 112 mm

Weight: 4.2 kg

Height: 112 mm

Width: 262 mm

Max. frequency: 3.6 GHz

: Manufacturer's standards (no certificate)

Voltage supply: Mains

Type: DSG836A

Min. frequency: 9 kHz

Product type: Mains-powered

Documents & Downloads

Datasheet

Datasheet 2187956 Rigol DSG836A Mains-powered 9 kHz - 3.6 GHz

User & Safety Instructions

User & Safety Instructions 2187956 Rigol DSG836A Mains-powered 9 kHz - 3.6 GHz

Description

The Model DSG836 HF Generator is used in hobby areas as well as in professional applications. With a range of software tools and possible accessories, ideal for EMI (EMC) pre-compiance testing. An IQ modulation is already integrated!

This text is machine translated.

Features

50MHz, 2 channel arbitrary function generator, 250Sa/sec sampling rate, 16 MioPt. Memory per channel, 4.3 inch touch color display . LAN, USB interfaces.
Up to -112 dBc/Hz (typical) phase noise
Up to +20 dBm (typical) maximum output power
Higher amplitude accuracy up to 0.5 dB (typical)
Excellent signal stability
Flexible frequency and amplitude sweep functions
Complete analogueue modulation functions ON/FM/ØM.
Standard LF output function
Powerful pulse modulation function
Open vector modulation function
System flatness calibration function
Simple and easy to use
Special design that ensures its reliability and durability
Specially developed protection functions
Digital ALC circuit
Simple structure
Take up less space in the rack
Lightweight
