Name: Schabus GX-D33 Carbon dioxide detector for CO2 cylinders mains-powered detects Carbon dioxide
Brand: Schabus
SKU: 2239485
Availability: BackOrder

White plug-in device with a digital display reading '30.0%', likely a rechargeable battery or power meter.

Advertisement for CO₂ pressure cylinders and technical equipment; demonstrates early detection of dangerous CO₂ leaks, Note: not suitable for room air CO₂ measurement, CO₂ sinks downwards.

Warning Graphic: A sensor detects a CO2 leak from a gas cylinder; text emphasises that CO2 is invisible, odourless and heavier than air.

Advertisement comparison: Left CX-D33 for technical installations detects genuine CO2 leaks; right standard CO2 detector for room air, unsuitable for leaks.

Infographic: GX-D33 CO2 Alarm is ready for operation within minutes; plug in, automatic initialisation after 3 mins., then protection active.

Advertising graphic for CO2 monitor GX-D33 in technical installations: shows device with display 0.58%, NDIR sensor, 85 dB alarm, high alarm threshold and continuous operation.

CO2 cloud and alarm siren with text 'Alarm activation according to DIN EN 6653-2' on white background.

1/7

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 30 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 169.99 / piece)

€ 200.00

-15 %

€ 169.99

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by SYGONIX

Sygonix Carbon monoxide detector incl. 10-year battery, incl. built-in sensor battery-powered detects Carbon monoxide

Fast track dispatch on Thu 29 Oct

€ 24.99

incl. VAT plus

Highlights & Details

Schabus GX-D33 Carbon monoxide detector for CO2 bottles

Audio and visual warning

Technical specifications

Operating voltage 230 (+/-10%) V AC / 50-60 Hz
Maximum power: approx. 3 W
Protection class: IP20
Sound pressure buzzer: 90 dB (distance 10 cm)
Sensor type: NDIR
Trigger concentration CO2: Approx. 2.5 - 3.0%vol.
Operating range sensor: 0 degrees / +40 degrees
Sensor life: Up to approx. 10 years

Product type: Carbon dioxide detector

Detector features: for CO2 cylinders

detects: Carbon dioxide

Power supply (LOV): mains-powered

Width: 60 mm

Height: 118 mm

Depth: 44 mm

Content: 1 pc(s)

Dim: (W x H x D) 60 x 118 x 44 mm

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2239485 Schabus GX-D33 Carbon dioxide detector for CO2 cylinders mains-powered detects Carbon dioxide

User & Safety Instructions

User & Safety Instructions 2239485 Schabus GX-D33 Carbon dioxide detector for CO2 cylinders mains-powered detects Carbon dioxide

Description

The warning device GX-D33 detects increased CO2 strain from faulty technical systems in interiors - however it ignores largely increased CO2 concentrations in bad air rooms.

1400 ppm CO2 in rooms is called "very bad air", the MAK is in Germany at 5000 ppm. The GX-D33 warns you much more than this. For instance, the alarm is triggered immediately upon defects at technical CO2-systems, which are under pressure, but in stressed rooms with a lot of people (e.g. open plan offices) the increased values are reliably ignored.

Loads in dry ice storage are also indicated by a loud alarm signal by the GX-D33 if there is no ventilation.

This text is machine translated.

Hints

Prior to installation, involve your trade association and the industrial inspectorate in your planning to ensure that nothing stands in the way of acceptance. There are clear regional differences over which Schabus has no influence on the electrical engineering.
