Name: Senseca ECO 511-135 pH / ORP meter pH, Temperature, ORP
Brand: Senseca
SKU: 3046628
Availability: InStock

'PH Meter' displaying a reading of 7.16 pH and 25.5°C, with a connected blue probe sensor.

A handheld digital display shows 'PH 7.16' and '25.5°C', indicating a measured pH level and temperature.

Handheld pH meter displaying a pH readout of 7.16 and temperature of 25.5°C. Device labeled 'Senseca' on top.

A blue sensor device with 'CND' on the left and 'T' on the right, featuring central electrical connectors and mounting holes.

A blue glass pH probe with a black cap and wire for measuring acidity or alkalinity in a solution.

A blue pH electrode sensor with a black cable, designed for measuring the acidity or alkalinity of solutions.

A blue and transparent cylindrical electrode probe with a black cable attached, used for measuring pH levels in scientific applications.

Senseca ECO 511-135 pH / ORP meter pH, Temperature, ORP-8

1/9

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 315.00 / piece)

€ 315.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

ECO 511-135 Waterproof pH/redox meter with Pt1000 input & alarm

Precise pH meter ECO 510 incl. pH-electrode GE 135

Technical specifications

Cable length max. 3 m
Power consumption: Less than 1 mA
Battery life: More than 3000 h typical Continuous operation
Automatic switch-off
Protection class IP65/IP67
Casing material: Unbreakable ABS, polyester (front panel)

Product type: pH / ORP meter

Reading type: pH
Temperature
ORP

Accuracy: ±0.02 pH ± 1 digit (at nominal temperature 25 °C)

Display: Digital

Operating temperature: -20 to +50 °C

Power supply (details): 2 x AA alkaline batteries

Dim: (L x W x H) 108 x 54 x 28 mm

Weight: 341 g

Temperature reading range: -5.0 up to +105.0 °C

Temperature reading range (max.): +105.0 °C

Temperature reading range (min.): -5.0 °C

pH reading range: 0.00 - 14.00 pH

pH reading range (max.): 14.00 pH

pH reading range (min.): 0.00 pH

Width: 54 mm

Height: 28 mm

Length: 108 mm

Interfaces: BNC

Documents & Downloads

Datasheet

Datasheet 3046628 Senseca ECO 511-135 pH / ORP meter pH, Temperature, ORP

User & Safety Instructions

User & Safety Instructions 3046628 Senseca ECO 511-135 pH / ORP meter pH, Temperature, ORP

Description

While developing the ECO 51x series, the focus was on the essential functions of the measurement technology. The Pure measurement with focus on precision, speed and reliability, packed in a compact housing enables the outstanding price-performance ratio, made in Germany. The hand-held measuring devices impress through their ergonomic design, the dust and water-protected design according to IP 65/67 and the illuminated display. The pH-meters are a real alternative to pH-sticks on the one hand and to high-priced, complex devices on the other. The measuring device ECO 510 enables measurements in the pH range, the ECO 511 offers additionally the possibility of measuring in the pH/redox range with temperature input (Pt1000). The measuring devices can be used in the areas of aquariums, acuqa and water monitoring, plant breeding, agricultural culture, in laboratories, quality assurance, service and food.

Display
The three-line LCD display provides ergonomic wide-angle visibility thanks to the backlight – during the day and at night
The HOLD function makes it possible to freeze the displayed values

Power Supply
2 powerful AA-batteries, the power-saving design and the configurable automatic switch-off provide for a long operation
Configurable LCD-background lighting for other power saving possibilities

calibration
Regular calibration with the recommended GPH-DOS 4 /7/10 results in excellent accuracy for its device class

This text is machine translated.
