SIROX 601.450.03 Add-on socket IP54 Grey
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.93
5
6% = € 0.19
€ 2.74
10
9% = € 0.27
€ 2.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.93 / piece)
€ 3.35
-13 %
€ 2.93
plus VAT.
Highlights & Details
Machine earthing contact socket-outlet, grey
- IP54
Technical specifications
- Flange size 50 x 50 mm
- Mounting depth 25 mm
- Product type
Add-on socket
- Outlets
1
- Nominal voltage
230 V
- Nominal current
16 A
- Mounting type
Enclosure
Recess-mount
- Design type
With cover
- Recess diameter
43 mm
- Mounting depth
25 mm
- Flange dimensions
50 x 50 mm
- Factory colour
Grey
IP54
- Dim
(W x H x D) 50 x 65 x 43 mm
- Width
50 mm
- Height
65 mm
- Depth
43 mm
- Content
1 pc(s)
- Max. load capacity
16 A
- Operating voltage
230 V AC
Documents & Downloads
Datasheet
Datasheet 624007 SIROX 601.450.03 Add-on socket IP54 Grey
Description
Socket with hinged lid and extruded flange gasket, water-proof. Lawn mowers, choppers, concrete mixers, circular saws etc. flange measurement 50 x 50 mm.
