Name: TAMS Elektronik 53-04146-01-C BST LC-NG-14 Flashing control circuits Fairground lighting 1 pc(s)
Brand: TAMS Elektronik
SKU: 2373300
Availability: InStock

Technical specifications

Size: Universal

Product type: Flashing control circuits

Functions: Fairground lighting

Type: Prefab component

Age category: 15 years and over

Manufacturer part #: 53-04146-01-C

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2373300 TAMS Elektronik 53-04146-01-C BST LC-NG-14 Flashing control circuits Fairground lighting 1 pc(s)

Warranty Terms

Warranty Terms 2373300 TAMS Elektronik 53-04146-01-C BST LC-NG-14 Flashing control circuits Fairground lighting 1 pc(s)

Description

Generation of the light sequences typical for rides, carousel or street fair booths, which are repeated after switching on in an endless loop. 5 variations to choose from based on real models: Break Dance No. 2, Booster, Ghost Temple and Top Spin.

This text is machine translated.

Features

14 outputs (max. 200 mA each) for connecting incandescent lamps or LEDs (via series resistors)
Note: In order to create prototypical lighting effects, it is necessary to R. a larger number of lights can be connected to an output. Because of their high power consumption, small lamps are therefore only suitable to a limited extent
Maximal total current: 1,000 mA
Using the switching input: Setting the variant (one of five)
Settings on the trim potentiometer: Speed of the process
Supply voltage: 12 - 18 V AC or 10 - 22 V DC.

Hints

Lamps and LEDs are not included.
