TracoPower TMPW 5-112-J SMPSU 12 V DC 0.42 A 5 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 22.99 / piece)
€ 22.99
incl. VAT
Only 7 Piece(s) available
Highlights & Details
AC/DC-Switching power supply, TMPW 5-J-Series
- Output 12 V DC / 0.42 A
- Power 5 W
- Jack connector
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
305 V AC
- Max. output current
0.42 A
- Output current (max.) - rounded
420 mA
- Min. input voltage
90 V AC
- Dim
(L x W x H) 55.1 x 43.2 x 23.0 mm
- Output voltage (max.)
12 V DC
- Connection
Jack connector
5 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-40 °C
- Weight
60 g
- Width
43.2 mm
- Height
23.0 mm
- Length
55.1 mm
- Type
TMPW 5-112-J
- Max. temperature
70 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
