TracoPower TPP 30-148-J SMPSU 48 V DC 0.63 A 30 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 71.99 / piece)
€ 71.99
incl. VAT
Only 2 Piece(s) available
Highlights & Details
AC/DC-Switching power supply, TPP 30-Series
- Output 48 V DC / 0.63 A
- Power 30 W
- Jack connector
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
0.63 A
- Output current (max.) - rounded
630 mA
- Min. input voltage
85 V AC
- Dim
(L x W x H) 100.3 x 38.1 x 25.4 mm
- Output voltage (max.)
48 V DC
- Connection
Jack connector
30 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
85 °C
- Max. operating temperature (derating)
60 °C
- Operating temperature (min.)
-40 °C
- Weight
119 g
- Width
38.1 mm
- Height
25.4 mm
- Length
100.3 mm
- Type
TPP 30-148-J
- Output current (min.)
0 mA
- Output voltage (min.)
48 V DC
- Max. temperature
85 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 1972324 TracoPower TPP 30-148-J SMPSU 48 V DC 0.63 A 30 W
Datasheet 1972324 TracoPower TPP 30-148-J SMPSU 48 V DC 0.63 A 30 W
User & Safety Instructions
User & Safety Instructions 1972324 TracoPower TPP 30-148-J SMPSU 48 V DC 0.63 A 30 W
