Buy TracoPower TXLN 060-105 AC/DC PSU module (+ enclosure) 5 V DC 10 A 50 W

Three metal power supplies of different sizes with ventilation grilles and connections. On the left, 'TANOS Technik' is written on a red label.

Datasheet (PDF)

3 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 48.73 / piece)

€

Only 3 Piece(s) available

Report legal concerns

Highlights & Details

AC/DC PSU Components

Output 5 V DC / 10 A
Power 50 W
Screw terminal

Technical specifications

Max. output current: 10 A

Output current (max.) - rounded: 10 A

Dim: (L x W x H) 110.8 x 82.0 x 28.0 mm

Height: 28.0 mm

Length: 110.8 mm

Width: 82.0 mm

Connection: Screw terminal

Type: closed

Type: TXLN 060-105

MTBF: 335000 h

Input voltage (max.): 264 V AC

Min. input voltage: 88 V AC

Operating temperature (max.): 70 °C

Operating temperature (min.): -20 °C

Max. operating temperature (derating): 50 °C

Output current (min.): 0 mA

Output voltage (max.): 5 V DC

Output voltage (min.): 5 V DC

No. of outputs: 1 x

: 50 W

PFC: No

Weight: 340 g

Product type: AC/DC PSU module (+ enclosure)

Documents & Downloads

Datasheet

Datasheet 2475577 TracoPower TXLN 060-105 AC/DC PSU module (+ enclosure) 5 V DC 10 A 50 W

User & Safety Instructions

User & Safety Instructions 2475577 TracoPower TXLN 060-105 AC/DC PSU module (+ enclosure) 5 V DC 10 A 50 W

Warranty Terms

Warranty Terms 2475577 TracoPower TXLN 060-105 AC/DC PSU module (+ enclosure) 5 V DC 10 A 50 W
