TracoPower TXM 015-112 SMPSU 13.2 V DC 1.3 A 15 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 25.99 / piece)
€ 25.99
incl. VAT
14-day return policy included
Highlights & Details
AC-DC power supply, 15 W, 12 V/1.3 A
- Very compact metal cased power supplies
- Cost optimized design
- High operating temperature up to 70°C
- Low no load power consumption <0.5W up to 75 W units
- Screw terminal block
- No internal fan up to 150 W models
- Universal input AC input full range
- Withstand 300 VAC surge input for 5 s
- Adjustable output voltage
- 3-year product warranty
Technical specifications
- Input voltage range: 90-264 VAC
- Output voltage range (adjustable): 11.4-13.2 VDC
- Output current: 1.3 A
- Power: 15 W
- Efficiency: 82 % (at 230 VAC)
- Regulation: Input variation: 0.5 % max., Load variation (10-100 %): 2.0 % max
- Over load protection mode: constant power, automatic recovery (Hiccup mode)
- Over voltage protection: 105-150 % of Vout norm
- Operating temperature range: see datasheet, Derating: see datasheet
- I/O isolation: 3000 VAC (60 s)
- Safety standards: cUL/UL 60950-1,IEC/EN 60950-1, CB scheme
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
1.3 A
- Output current (max.) - rounded
1.3 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 51 x 90.6 x 28.8 mm
- Output voltage (max.)
13.2 V DC
- Connection
Screw terminal
15 W
- Type
closed
- Weight
165 g
- Width
90.6 mm
- Height
28.8 mm
- Length
51 mm
- Type
TXM 015-112
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1083057 TracoPower TXM 015-112 SMPSU 13.2 V DC 1.3 A 15 W
Datasheet 1083057 TracoPower TXM 015-112 SMPSU 13.2 V DC 1.3 A 15 W
User & Safety Instructions
User & Safety Instructions 1083057 TracoPower TXM 015-112 SMPSU 13.2 V DC 1.3 A 15 W
Warranty Terms
Warranty Terms 1083057 TracoPower TXM 015-112 SMPSU 13.2 V DC 1.3 A 15 W
Description
The TRACOPOWER TXM series is a family of encased power supplies designed for a wide range of cost critical applications. With a low profile metal case and screw terminal block connection, they are easy to install in any equipment. There are 40 models with single output voltages from 3.3 VDC to 48 VDC in 9 power ranges from 15 W to 320 W. These power supplies have universal input and comply with European EMC standards and the Low Voltage Directive (LVD).
Scope of delivery
- AC-DC power supply
