TRU COMPONENTS Pin strip (standard) No. of rows: 2 Pins per row: 10 1580930 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
93 Piece(s) (Only while stocks last)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
5
-
€ 0.61
15
8% = € 0.05
€ 0.56
25
10% = € 0.06
€ 0.55
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 5
Total (€ 0.61 / piece)
€
Highlights & Details
- Content 1 pc(s)
- No. of rows 2
- Pins per row 10
Technical specifications
- Connector type
Pin strip, right angle
- No. of rows
2
- Pins per row
10
- Total number of pins
20
- CS
2.54 mm
- Connection
Print
- Factory colour
Black
- Pin shape
Rectangular
- Nominal voltage
1000 V
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Contact surface
Gold plated
- Contact material
Copper alloy
- Case material
Thermoplastic material
- Pin length (receptacle)
4 mm
- Pin length (PCB)
2.80 mm
- Separable
No
- Dim
(L x W x H) 25.40 x 10.35 x 7.8 mm
- Manufacturer part #
1580930
- Content
1 pc(s)
- Height
7.8 mm
- Length
25.40 mm
- Width
10.35 mm
- Industrial packaging
No
- Type
1580930
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-55 °C
- Product type
Pin strip (standard)
Documents & Downloads
Datasheet
Datasheet 1580930 TRU COMPONENTS Pin strip (standard) No. of rows: 2 Pins per row: 10 1580930 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1580930 TRU COMPONENTS Pin strip (standard) No. of rows: 2 Pins per row: 10 1580930 1 pc(s)
