VOKA Kabelwerk 10084050 Telecom cable J-Y(ST)Y 8 x 2 x 0.6 mm² Grey (RAL 7032) 500 m
EAN:
Part number:
Item no:
Product type
Telecom cable
Cable type
J-Y(ST)Y
No. of leads
16 x
Cross section (each core)
0.6 mm²
Content
500 m
Datasheet (PDF)
Number
Total (1 m = € 1.43)
€ 713.45
plus VAT.
Technical specifications
- Product type
Telecom cable
- Cable type
J-Y(ST)Y
- No. of leads
16 x
- Cross section (each core)
0.6 mm²
- Cross section
8 x 2 x 0.6 mm²
- Cable features
Halogen-free
rigid core
Metal foil shield
- Outside Ø
8.1 mm
- Factory colour
Grey (RAL 7032)
- Content
500 m
- Nominal voltage
300 V AC
- Test voltage
800 V AC
- Bend radius (no. of ODs for fixed installation)
8
- Bend radius (no. of ODs for flexible installation)
8
- Sold per metre
No
- Halogen-free
Yes
- Shielded
Yes
- Manufacturer part #
10084050
- Insulation material
PVC
- Min. temperature range (fixed installation)
-30 °C
- Max. temperature range (fixed installation)
70 °C
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
50 °C
- Certification marks
VDE 0815
- Type
10084050
- Max. length sold by the metre
500 m
- Twisted pair cabling (part 1)
Yes (1)
Documents & Downloads
Datasheet
Datasheet 2358984 VOKA Kabelwerk 10084050 Telecom cable J-Y(ST)Y 8 x 2 x 0.6 mm² Grey (RAL 7032) 500 m
User & Safety Instructions
User & Safety Instructions 2358984 VOKA Kabelwerk 10084050 Telecom cable J-Y(ST)Y 8 x 2 x 0.6 mm² Grey (RAL 7032) 500 m
Description
For transmission of messages in dry and damp operating locations, in and under plaster, in the open during fixed installation. Not approved for high-current installation and underground installation.
