WAGO 250-603/000-006 Spring-loaded terminal 1.00 mm² Number of pins 3 Blue 200 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 200 pc(s))
Total (€ 197.47 / piece)
€
Technical specifications
- PCB KL-LEISTE RASTER 7,5MM 3-P.GRAU
- Features
+ CAGE CLAMP®
- CS
7.50 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Series
250
- Min. stripping length
9 mm
- Stripping length (max.)
10 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
17.5 A
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
17.5 A
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
1.00 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
20
- Connector orientation
At an angle (to the PCB)
- AWG max.
16
- Contact material
Cathode copper, tin plated
- Enclosure material
Polyamide
- Factory colour
Blue
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Content
200 pc(s)
- Height
20.50 mm
- Length
13.00 mm
- Width
21.50 mm
- Industrial packaging
Yes
- Manufacturer part #
250-603/000-006
- Type
250-603/000-006
- Nominal voltage
630 V
- Product type
Spring-loaded terminal
