WAGO 280-565/280-321 Actuator terminal 6 mm Pull spring Configuration: L Grey 50 pc(s) Package

Grey clamp with orange protection; designed for electrical connections in control panels. Mountable on DIN rails.
'Two circuit diagrams: Above, a line with a circle connects a blue resistor. Below, a line with a switch connects two terminals S.'
'Cross-section of an electrical connection with an orange housing, 55.5 mm in height, 80 mm in length. Technical drawing with dimensions.'
1/3
Packaging type
Package
Product type
Actuator terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 20 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 4.50 / piece)
€ 224.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Actuator terminal block

  • 280-565/280-321
  • Industrial packaging, pack of 50

Technical specifications

  • ACTUATOR TERMINAL BLOCK WITH END PLA
Packaging type

Package

Product type

Actuator terminal

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

6 mm

No. of rows

2

Number of pins

3

Factory colour

Grey

Nominal current

5 A

Nominal current - rounded value

5 A

Nominal voltage

125 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-565/280-321

Content

50 pc(s)

Industrial packaging

Yes

Type

280-565/280-321

Dim

(W x H) 6 mm x 55.50 mm

Width

6 mm

Height

55.50 mm

Connector colour

Grey

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 535865 WAGO 280-565/280-321 Actuator terminal 6 mm Pull spring Configuration: L Grey 50 pc(s) Package

User & Safety Instructions

User & Safety Instructions 535865 WAGO 280-565/280-321 Actuator terminal 6 mm Pull spring Configuration: L Grey 50 pc(s) Package

Description

For fuse plugs, the phase protection with cover plate, for pressure switch, thermostat switch, gray.
