WAGO 280-685 N terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Package

Grey-white electrical terminal block with multiple connection points, copper wire connections visible, suitable for industrial applications.
Grey two-tier terminal block with dimensions: width 32 mm, depth 75 mm, height 52.5 mm. Displays internal structure.
1/2
Packaging type
Package
Product type
N terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Wed 18 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 50 pc(s))
Total (€ 3.50 / piece)
€ 174.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

4-conductor disconnect terminal block

  • 280-685
  • Industrial packaging, pack of 50

Technical specifications

  • 4COND.DISCON.TERM.BLOCK 2,5SQMM GREY
Packaging type

Package

Product type

N terminal

Features

+ separator

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

5 mm

No. of rows

1

Pins per row

4

Number of pins

4

Factory colour

Grey

Nominal current

10 A

Nominal current - rounded value

10 A

Nominal voltage

400 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-685

Content

50 pc(s)

Industrial packaging

Yes

Type

280-685

Dim

(W x H) 5 mm x 52.50 mm

Width

5 mm

Height

52.50 mm

Contamination level

3

Flammability rating

V0

Insulation material

Thermoplastic

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 536106 WAGO 280-685 N terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Package

User & Safety Instructions

User & Safety Instructions 536106 WAGO 280-685 N terminal 5 mm Pull spring Configuration: L Grey 50 pc(s) Package

Description

+ separator, gray.
