Absima CR4S Pistol grip RC 2,4 GHz No. of channels: 4
EAN:
Part number:
Item no:
Number
Total (€ 36.97 / piece)
€ 36.97
plus VAT.
Highlights & Details
4-channel remote control "CR4S" 2.4GHz incl. receiver R4WP-Micro
- 4 channelsBeginner modeSecure 2.4 GHz transmission technologyIncludes 4-channel receiver
Technical specifications
- Protocol: ANTDistance: Up to 150 m.Low V warning: To 4.2V (NiMH only)Use only LiPo battery with built-in Low V protection functionInternal antennaTemperature range: -10 to +60 °C.Remote control dimensions (LxWxH): 118x73x145 mmWeight of remote control: Approx. 130 g4 channels receiverExternal with antenna pipeWaterproof receiverOperating voltage receiver 3.5-8.4VReceiver with fail-safe in connection with remote controlReceiver dimensions (LxWxH): 30.2x18 x 13 mmReceiver weight 5 g
- Frequency
2,4 GHz
- Channels
4
- Weight
130 g
- Factory colour
Black
- Product type
Pistol grip RC
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2536522 Absima CR4S Pistol grip RC 2,4 GHz No. of channels: 4
Description
The "CR4S" is a 4-channel remote control including receiver, which uses the latest AFHDS 2.4GHz "ANT" frequency jump technology from ABSIMA. Light and compact design, as well as comfortable and ergonomically shaped. Moreover, the remote control has a "beginner mode" and is therefore also suitable for pilots with little experience and also children. The receiver included in the delivery is very compact in design with a size of 30.2x18 x 13 mm and fits in almost every receiver box.
This text is machine translated.
This text is machine translated.
Features
- The transmitter has 4 channels which are divided as follows) - CH1: Steering wheel / CH2: Throttle (trigger) / CH3: 3-position toggle switch / CH4: Push buttonReverse function (REV): With this function you can set the direction of rotation of the steering servo/motorTrim (TRIM): Sets the straight run and the throttle neutral positionDual rate function (D/R): By pressing the rotary controls, the steering angle or the motor rotation power can be increased/reducedFail-safe function: This function specifies what the receiver should pass on if the signal to the transmitter has been lost (e.g. emergency braking)Beginner mode: This function is intended for beginners. In this mode, the engine power is automatically reduced to 50%
Scope of delivery
- CR4S remote control
- R4WP micro receiver
- Antenna pipe
- User manual
