binder 09 0123 300 06 Mini DIN connector Sleeve plug Total number of pins: 6 1 pc(s)
Product type
Mini DIN connector
Connector type
Sleeve plug
Total no. of pins
6
Connection
Soldering
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 14.99 / piece)
€ 14.99
incl. VAT
14-day return policy included
Technical specifications
- Type
09 0123 300 06
- Product type
Mini DIN connector
- Connector type
Sleeve plug
- Total no. of pins
6
- Connection
Soldering
- Content
1 pc(s)
- Max. temperature
+95 °C
- Nominal current
5 A
- Min. temperature
-40 °C
- Nominal current - rounded value
5 A
- Seal
Screws
- Leading contact (PE)
No
- Nominal voltage
250 V
- Contact material
CuZn
- Case material
PBT, UL94V-0
20
- Connection angle
180°
- Manufacturer part #
09 0123 300 06
- Number of pins
6
- max. cross section
0.75 mm²
- Cross-section range
0.75 mm² (max)
IP67
Documents & Downloads
Datasheet
Datasheet 1663624 binder 09 0123 300 06 Mini DIN connector Sleeve plug Total number of pins: 6 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1663624 binder 09 0123 300 06 Mini DIN connector Sleeve plug Total number of pins: 6 1 pc(s)
