Connector module Phoenix Contact 2901645 Content: 1 pc(s)

The mini patch panel represent the transition of the field cabling for internal wiring closet switching. The connection from the patch panel to end device is equipped with a pre-patch cord to the RJ45 socket. The field cabling, depending on the version simply on the screw or LSA-connection terminals. The respective terminals are clearly for connection to Ethernet standard TIA 568A and B as well as PROFINET labelled. The elaborate crimping of an RJ45 plug is connected to the field line is omitted. The shield contact with the mounting rail, you can use a jumper either directly or via a rcmember.

This text is machine translated.
