Dehner Elektronik SPS 360P-24 (24VDC Industrial PSU 24 V DC 15 A 360 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 189.99 / piece)
€ 189.99
incl. VAT
14-day return policy included
Highlights & Details
Industrial power supply SunPower SPS 360P-24 Dehner Elektronik GmbH
- Output 24 V DC / 15 A
- Power 360 W
- Screw terminal
Technical specifications
- Number of output voltages: 1 - SingleApplication: Information technology, industryOutput connection: Screw terminalDesign: Housing power supplyInput Connection: Screw terminalApplicable in region: Europe, USA / CanadaProtection class: Protection class I.
- Product type
Industrial PSU
- Input voltage (max.)
264 V AC
375 V DC
- Max. output current
15 A
- Output current (max.) - rounded
15 A
- Min. input voltage
85 V AC
120 V DC
- Dim
(L x W x H) 198 x 99 x 38 mm
- Output voltage (max.)
24 V DC
- Connection
Screw terminal
360 W
- No. of outputs
2 x
- Type
closed
- Operating temperature (max.)
50 °C
- Max. operating temperature (derating)
70 °C
- Operating temperature (min.)
-20 °C
- Weight
730 g
- PSU features
Regulated
- Type
Switched PSU
- Width
99 mm
- Height
38 mm
- Length
198 mm
- Type
SPS 360P-24 (24VDC
- MTBF
144000 h
- Output voltage (min.)
24 V DC
- PFC
Yes
- Max. temperature
80 °C
- Min. temperature
-40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2584528 Dehner Elektronik SPS 360P-24 (24VDC Industrial PSU 24 V DC 15 A 360 W
User & Safety Instructions
User & Safety Instructions 2584528 Dehner Elektronik SPS 360P-24 (24VDC Industrial PSU 24 V DC 15 A 360 W
Warranty Terms
Warranty Terms 2584528 Dehner Elektronik SPS 360P-24 (24VDC Industrial PSU 24 V DC 15 A 360 W
Description
High-quality switched-mode power supply suitable for industrial, IT and audio video applicationsSpecificationLow operating costs due to high energy efficiencyOutput voltage adjustable ± 10%Remote sense for output voltageRemote control ON/OFFStandard mounting device, thus identical to products of other power supply manufacturersHigh service life due to the installation of high-quality components, high MTBF rateProtection measures against overload, overvoltage and short circuit with automatic restartWide-range voltage input (alternating voltage and direct voltage)· Increased temperature range of +70 ºC with deratingCan be used up to 5000 m above sea levelHigh efficiency through modern switching technologyNo minimum load requiredTested according to EN, UL, CB. Internationally adjustable
This text is machine translated.
This text is machine translated.
Scope of delivery
- User manual
