Buy Einhell 4170773 GC-DP 1020 N Effluent sump pump 18000 l/h 9 m

Einhell Submersible Pump, silver, with black hose and orange float switch, Model GC-DP 1020 N, for water transfer.

A person is collecting water from a well using a submersible pump in a wooded garden area.

'Cross-section of a mechanical device with red and grey components, showing gears and axles, with emphasis on internal mechanisms.'

'Illustration of a submersible pump with electrical connection. Shows maximum and minimum immersion depths along with diameter and connection specifications.'

Diagram of a Water Pump: Maximum Depth 5 m, Maximum Height 9 m, Minimum Size 40 x 40 cm, Maximum Temperature 35 °C, 230 V – 50 Hz, 1000 W.

Various black plastic pipe connectors on a white background. Includes angled and straight coupling pieces.

1/8

Datasheet (PDF)

Fast track dispatch on Thu, 17 Sep

43 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 73.94 / piece)

€ 73.94

plus VAT.

Report legal concerns

Einhell Dirt water pump GC-DP 1020 N

Highlights & Details

High-quality mechanical seal

Technical specifications

Water temperature up to 35°C
Switching point: approx. 50 cm
Switching point: approx. 5 cm

Product type: Effluent sump pump

Max. delivery head: 9 m

Max. feed rate: 18000 l/h

Max. discharge pressure: 0.9 bar

Operating voltage: 230 V

Power consumption (P1): 1000 W

Pressure connection: 44.9 mm (1 1/2") IT

Max. size of solids: 20 mm

Immersion depth: 5 m

Max. cable length: 10 m

Float switch: Yes

Weight: 7.2 kg

: IPX8

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1326154 Einhell 4170773 GC-DP 1020 N Effluent sump pump 18000 l/h 9 m

User & Safety Instructions

User & Safety Instructions 1326154 Einhell 4170773 GC-DP 1020 N Effluent sump pump 18000 l/h 9 m

Warranty Terms

Warranty Terms 1326154 Einhell 4170773 GC-DP 1020 N Effluent sump pump 18000 l/h 9 m

Description

The waste water pump GC-DP 1020 N is a robust, powerful and reliable tool that provides the best service when pumping out ponds, excavation pits, flooded basements and much more. With a power consumption of 1,000 watts, the powerful pump delivers up to 18,000 liters of contaminated water every hour. The casing is made of high-quality stainless steel, which ensures a long running time. The high-quality mechanical seal of the GC-DP 1020 N protects the high-performance motor and ensures extensive maintenance-free operation. Your continuously adjustable float switch offers the choice between continuous operation and a pre-selected switch on and off level. For flexible connection options, the GC-DP 1020 N is equipped with a universal connection and a 90° angle. In addition, it has a carrying handle for easy transport.

This text is machine translated.
