Buy EPIC ® SIGNAL M23 E inserts, 12 pin D-Sub 44420120 44420120 LAPP Content: 5 pc(s)

Red round plastic rotary knob with printed numbers from 1 to 12 and the letter 'E' in the centre; commonly used in technical applications.

Image similar

'Connector Wiring Diagram: Diagram of a 12-pin connector with pins numbered from 1 to 12 and a central E contact.'

1/2

Image similar

Packaging type

Piece

Connector type

Plug

Connection

Crimp

Connector cross section

0.08 - 0.56 mm²

Rated voltage

100 V

Datasheet (PDF)

Fast track dispatch on Wed, 16 Sep

12 Set(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number (Package size 5 pc(s))

Set(s)

Total (€ 1.34 / piece)

€ 6.71

plus VAT.

Report legal concerns

Technical specifications

For D-Sub band contacts
For Crimper

Packaging type: Piece

Connector type: Plug

Connection: Crimp

Connector cross section: 0.08 - 0.56 mm²

Rated voltage: 100 V

Test current: 4 A

Total no. of pins: 12

Manufacturer part #: 44420120

Industrial packaging: Yes

Content: 5 pc(s)

Number of pins: 12

RoHS-compliant: Yes

Features: Right-hand

Type: 44420120

Leading contact (PE): No

Type: E-part, right-hand

UKCA: yes
