Feed-through terminal block UDK 4 BU 2775090 Phoenix Contact
Packaging type
Package
Product type
Serial continuity
Connection
Screws
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
6 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 4.20 / piece)
€ 209.99
incl. VAT
14-day return policy included
Highlights & Details
Feed-through terminal block UDK 4 BU
- UDK 4 BU
Technical specifications
- Packaging type
Package
- Product type
Serial continuity
- Features
with screw connection
- Connection
Screws
- Cross section (flexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
24
- AWG max.
10
- Clamp width
6.2 mm
- No. of rows
1
- Pins per row
1
- Number of pins
4
- Factory colour
Blue
- Nominal current
32 A
- Nominal current - rounded value
32 A
- Nominal voltage
630 V
- Stripping length (max.)
8 mm
- Manufacturer part #
2775090
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
UDK 4 BU
- Dim
(L x W x H) 63.5 x 6.2 x 47 mm
- Width
6.2 mm
- Height
47 mm
- Length
63.5 mm
- Contamination level
3
- Flammability rating
V2
- Insulation material
PA
- Insulation
PA
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 565164 Feed-through terminal block UDK 4 BU 2775090 Phoenix Contact
User & Safety Instructions
User & Safety Instructions 565164 Feed-through terminal block UDK 4 BU 2775090 Phoenix Contact
Description
1-level terminal block with double connection on both sides, cross section: 0.2 - 2.5 mm², AWG: 24 - 10, width: 6.2 mm, color: blue
