Foscam V5EP (black) LAN IP CCTV camera 3072 x 1728 p
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 60.50 / piece)
€ 60.50
plus VAT.
Highlights & Details
LAN IP-Bullet camera;3072 x 1728 p;Foscam;V5EP (black)Outdoors
- High-resolution 5 MP video by day and night
- H.265/H.264 Video compression
- PoE
- Intelligent detection of persons and vehicles
- P2P-function for easy remote access
- Integrated spotlight and an acoustic siren
Technical specifications
- Headlight: Colour temperature: 4500K
- Sensor: High-resolution color CMOS sensor
- Resolution 5.0 mega pixel (3072 x 1728)
- Min Illumination 0 lux (with IR lamp)
- Viewing angle: Horizontal: 82.3 °, vertical 52.5 °, diagonal: 110 °
- Image compression: H.265/H.264
- Resolution 5 MP (3072 x 1728), 1.5 M / 15 fps, 1080P (1920 x 1080) 1 M/25 fps, 720P (1280 x 720) 1 M/15 fps
- Audio compression: PCM/AAC
- Ethernet 10/100 Mbit/s RJ45 port
- POWER CONNECTION DC 12 V/1.0 A
- Product type
CCTV camera
- CCTV features
IR LEDs
White spotlight
Sounder
ONVIF support
2-way communication
Speaker
Microphone
Identity recognition
Vehicle recognition
PoE IEEE 802.3af
- Camera type
Bullet camera
- Resolution (max.)
3072 x 1728 p
- Sensor type
CMOS
Alexa
Google Home
Manufacturer-specific
- Focal length
4 mm
- Max. viewing angle hor.
82.3°
- Vertical viewing angle
52.5°
- Vertical viewing angle
110°
- Transfer type
LAN
- Light sensitivity (+ IR)
0 lx
- IR range (max.)
20 m
- Used at
Outdoors
- Width
66 mm
- Height
66 mm
- Depth
170 mm
- Dim
(W x H x D) 66 x 66 x 170 mm
- Weight
342 g
- F-numbers
2.1
- Factory colour
Black
IP66
- Signal standard
IP
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2894440 Foscam V5EP (black) LAN IP CCTV camera 3072 x 1728 p
User & Safety Instructions
User & Safety Instructions 2894440 Foscam V5EP (black) LAN IP CCTV camera 3072 x 1728 p
Description
The Foscam V5EP is a PoE (power-over-Ethernet) 5 MP POE surveillance camera, which enables an easy installation. The camera can be used both during the day and at night and is weather-proof in order to withstand all weather conditions.
The camera is compatible with the Foscam NVR (network video recorder). This enables seamless integration into an existing monitoring system supported by the Foscam NVR.
With its high resolution of 5 megapixels, the Foscam V5EP offers clear and sharp images, which can record details and subtleties. The camera has advanced functions such as motion detection, detection of people and vehicles, email notifications and remote access via a mobile APP to ensure the monitoring is possible anytime and anywhere.
The advanced detection of people and vehicles in the Foscam V5EP 5 MP POE IP camera is a great feature that helps minimize unwanted alarms and detect only real security risks. Focussing on the detection of persons and vehicles enables the surveillance camera to ignore the movements of branches, flying insects or other moving objects, which would otherwise lead to false alarms.
The Foscam V5EP 5 MP POE IP camera has a built-in microphone and speaker that enables real-time communication with the people captured by the camera. Two-way communication is an important supplement to the surveillance function of the camera and enables you even more control and interaction with the environment to be monitored.
The Foscam V5EP 5 MP POE IP security camera is equipped with an integrated spotlight and a siren that are activated when an intruder is detected. This can be an effective deterrent and helps to prevent break-in and other damage. The camera can be set so that the headlights and siren are activated automatically when movement is detected. The maximum volume of the alarm siren is 100 dB, WAS is very loud and deterrent effect to potential intruders.
The Foscam V5EP 5 MP POE IP camera is compatible with Amazon Alexa and Google Assistant voice control. So you can control your camera with simple voice commands and view the live stream on a compatible Amazon or Google device.
The IP66-certified casing of the Foscam V5EP 5 MP POE surveillance camera was developed especially for ensuring protection against bad weather.
The weatherproof casing protects the camera against rain, snow, dust, dirt and other environmental influences. This allows the camera to be used in many different environments, including indoors and outdoors.
This text is machine translated.
The camera is compatible with the Foscam NVR (network video recorder). This enables seamless integration into an existing monitoring system supported by the Foscam NVR.
With its high resolution of 5 megapixels, the Foscam V5EP offers clear and sharp images, which can record details and subtleties. The camera has advanced functions such as motion detection, detection of people and vehicles, email notifications and remote access via a mobile APP to ensure the monitoring is possible anytime and anywhere.
The advanced detection of people and vehicles in the Foscam V5EP 5 MP POE IP camera is a great feature that helps minimize unwanted alarms and detect only real security risks. Focussing on the detection of persons and vehicles enables the surveillance camera to ignore the movements of branches, flying insects or other moving objects, which would otherwise lead to false alarms.
The Foscam V5EP 5 MP POE IP camera has a built-in microphone and speaker that enables real-time communication with the people captured by the camera. Two-way communication is an important supplement to the surveillance function of the camera and enables you even more control and interaction with the environment to be monitored.
The Foscam V5EP 5 MP POE IP security camera is equipped with an integrated spotlight and a siren that are activated when an intruder is detected. This can be an effective deterrent and helps to prevent break-in and other damage. The camera can be set so that the headlights and siren are activated automatically when movement is detected. The maximum volume of the alarm siren is 100 dB, WAS is very loud and deterrent effect to potential intruders.
The Foscam V5EP 5 MP POE IP camera is compatible with Amazon Alexa and Google Assistant voice control. So you can control your camera with simple voice commands and view the live stream on a compatible Amazon or Google device.
The IP66-certified casing of the Foscam V5EP 5 MP POE surveillance camera was developed especially for ensuring protection against bad weather.
The weatherproof casing protects the camera against rain, snow, dust, dirt and other environmental influences. This allows the camera to be used in many different environments, including indoors and outdoors.
This text is machine translated.
Features
- Stream: Dual-stream
- Image setting: Hue, brightness, contrast, saturation, sharpness are adjustable
- Mirror image function: Rotate and mirror
- Night mode: Manual and automatic mode when the white light is on, the night view image is colored
- Night vision: With 4 IR LEDs and headlights, night vision range up to 20 m.
- Input/output: Integrated microphone and speakers, 2-way audio possible in full-duplex real-time
- Siren: Max. 100 dB alarm siren
- Remote access P2P
- NETWORK PROTOCOL: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP, ONVIF
- Operating system: Microsoft Windows (Foscam VMS), Mac OS (Foscam VMS), Android (Foscam APP), IOS (Foscam APP)
- Motion detection: Upload alarm via e-mail, alarm snapshot on FTP
- Person recognition: Alarm via e-mail, upload alarm snapshot on FTP
- Vehicle detection: Alarm via e-mail, upload alarm snapshot to FTP
- User accounts: Three levels of user role
- Firewall: Supports IP filtering
- Reset: Reset button is available
- Intelligent Wizard: Supports Alexa, Google assistant
- Two-way audio with built-in microphone and speaker
- Supports SD cards with up to 256 GB for storing the video
- IP66 Water resistant.
Scope of delivery
- Foscam V5EP surveillance camera (black)
- Network cable
- Set of screws
- Quick guide
Hints
Memory card not included
