HARTING 09340102701 Socket inset Han® Hv E 10 + 2 + PE Screws 1 pc(s)
EAN:
Part number:
Item no:
Product type
Socket inset
Series
Han® Hv E
Connection
Screws
Total no. of pins
10 + 2 + PE
Core cross section (min.)
0.5 mm²
Number
Total (€ 47.05 / piece)
€ 47.05
plus VAT.
Only 1 Piece(s) available
Highlights & Details
HARTING 09340102701 Socket inset Han® Hv E 10 + 2 + PE Screws 1 pc(s)
Our service for you
Technical specifications
- Product type
Socket inset
- Factory colour
Grey
- Series
Han® Hv E
- Features
copper-plated
tin-plated contacts
- Connection
Screws
- Number of pins
10
2
- Total no. of pins
10 + 2 + PE
- Core cross section (min.)
0.5 mm²
- Core cross section (max.)
2.5 mm²
- Mating cycles
≥ 500
- Size
24 B
- Rated voltage
400/690 V(Leiter-Erde/Leiter-Leiter)
- Test current
16 A
- Content
1 pc(s)
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Leading contact (PE)
Yes
- Type
Socket insert
- Core connector
0.5 - 2.5 mm²
- Contamination level
3
- Connection
Screws
- Temperature range
-40 - +125 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 749644 HARTING 09340102701 Socket inset Han® Hv E 10 + 2 + PE Screws 1 pc(s)
Description
Heavy industrial connectors for the toughest requirements in automotive, machine and plant engineering. With 2 additional contacts for the activation.
