HARTING 09360083001 Pin inset Han® D 8 + PE Crimp 1 pc(s)
EAN:
Part number:
Item no:
Product type
Pin inset
Series
Han® D
Connection
Crimp
Total no. of pins
8 + PE
Core cross section (min.)
0.14 mm²
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€ 10.92
plus VAT.
Highlights & Details
HARTING 09360083001 Pin inset Han® D 8 + PE Crimp 1 pc(s)
Technical specifications
- Product type
Pin inset
- Factory colour
Grey
- Series
Han® D
- Connection
Crimp
- Number of pins
8
- Total no. of pins
8 + PE
- Core cross section (min.)
0.14 mm²
- Core cross section (max.)
2.5 mm²
- Mating cycles
≥ 500
- Size
3 A
- Rated voltage
250 V
- Test current
10 A
- Content
1 pc(s)
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Leading contact (PE)
Yes
- Type
Pin insert
- Core connector
0.14 -2.5 mm²
- Contamination level
3
- Connection
Crimp
- Temperature range
-40 - +125 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 749260 HARTING 09360083001 Pin inset Han® D 8 + PE Crimp 1 pc(s)
User & Safety Instructions
User & Safety Instructions 749260 HARTING 09360083001 Pin inset Han® D 8 + PE Crimp 1 pc(s)
Description
Connectors for high environmental requirements; loking clamp ensures high mechanical stability even under vibration or shock loads. Used in: engineering, wind power, cabinet construction, railroad engineering.
Hints
Reagents must be ordered separately!
