Joy-it RB-TFT3.2-V3 Touchscreen unit 8.1 cm (3.2 inch) 320 x 240 Pixel Compatible with (development kits): Raspberry Pi®
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 15.99 / piece)
€ 15.99
incl. VAT
Only 10 Piece(s) available
Highlights & Details
Resistive touch-screen module, 3.2" (8.13 cm), GPIO PI 4/5, 320x240 pixels
- Resistive single touch
- Compatible with PI4 / PI5
- 3 freely assignable buttons (GPIO23, GPIO24, GPIO25)
- Pin-controlled backlight (GPIO18)
Technical specifications
- Resistive single touch
- SPI
- 3 freely assignable buttons (GPIO23, GPIO24, GPIO25)
- Can be plugged directly into the Raspberry Pi
- Pin-controlled backlight (GPIO18)
- Controller XPT2046
- IC driver SSD1289
- Operating temperature: 0 °C to +70 °C
- Horizontal viewing angle: Up to 45 °
- Vertical viewing angle Top: Up to 45 ° Down: Up to 20 °
- Product type
Display
- Display technology
LED
- Display (cm)
8.1 cm
- Screen size diagonal (inches)
3.2 inch
- Suitable for
Raspberry Pi® 4 B
Raspberry Pi® 5 B
- Display resolution
320 x 240 Pixel
- Interfaces
GPIO
- Features
SBC slot
Backlighting
- Colour temperature
65536 K
- Brightness (max.)
350 cd/m²
- Length
60 mm
- Width
85 mm
- Height
20 mm
- Compatible with
Raspberry Pi®
Documents & Downloads
Datasheet
Datasheet 2987780 Joy-it RB-TFT3.2-V3 Touchscreen unit 8.1 cm (3.2 inch) 320 x 240 Pixel Compatible with (development kits): Raspberry Pi®
User & Safety Instructions
User & Safety Instructions 2987780 Joy-it RB-TFT3.2-V3 Touchscreen unit 8.1 cm (3.2 inch) 320 x 240 Pixel Compatible with (development kits): Raspberry Pi®
Description
Experience outstanding display and intuitive operation with our 3.2" display, specially developed for your Raspberry Pi. Despite its compact size, this display with a brilliant resolution of 320x240 pixels ensures that your content is always presented in bright colors and impressive sharpness. A special feature of this display is its adjustable LED-background lighting, which can be switched on or off directly via a GPIO-pin of the Raspberry Pi. In addition, the display stands out through its three freely programmable buttons. You can configure these as desired for a simple menu navigation, specific tasks or for quick access to certain functions. Their creativity is set to a minimum.
This text is machine translated.
This text is machine translated.
