Kingbright L-934SF4C IR emitter 880 nm 50 ° 3 mm Radial lead
Product type
IR emitter
Casing
3 mm
Type (LEDs)
Water clear
Non-tinted
Type
Radial lead
Forward voltage U(F)
1.3 V
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 7
Total (€ 0.48 / piece)
€ 0.59
-19 %
€ 0.48
incl. VAT
14-day return policy included
Technical specifications
- Product type
IR emitter
- Type
L-934SF4C
- Casing
3 mm
- Type (LEDs)
Water clear
Non-tinted
- Type
Radial lead
- Type
Clear
- Forward voltage U(F)
1.3 V
- Forward current I(F)
50 mA
- Radiation angle
50°
- Beam intensity I(e)
11 mW/sr
11 mW
- Wavelength
880 nm
- Manufacturer
Kingbright
11 mW
- Casing
3 mm
Documents & Downloads
Datasheet
Datasheet 154420 Kingbright L-934SF4C IR emitter 880 nm 50 ° 3 mm Radial lead
User & Safety Instructions
User & Safety Instructions 154420 Kingbright L-934SF4C IR emitter 880 nm 50 ° 3 mm Radial lead
Description
Hints
Unless LED chips come with a built-in current limiter, they need to be protected by a current-limitung resistor or constant current source. Infrared light wavelengths are invisible to the human eye.
