Highlights & Details

Wire rope shears forged KNIPEX 95 61 190

With two crimp profiles for ferrules on jackets and end caps for wire rope.
Comfortable working by handy, slim design and inner opening spring
Screwed joint for precise blade guide, operating positions
High translation for power saving work
Cutting hardness approx. 64 HRC

Technical specifications

Handle: Coated with rough, non-slip plastic

Product type: Wire rope cutter

Manufacturer part #: 95 61 190

Suitable for: Single/multi-core aluminium and copper cables
Medium wire ropes

Length: 190 mm

Material: Chromium-vanadium electric furnace steel

Material properties: tempered
polishing

Wire hardness diameter (max.): 7 mm

Wire hardness cross section (max.): 10 mm²

Wire hardness cross section AWG (max.): 7

Width: 60 mm

Weight: 314 g

Type: 95 61 190

Material suitability: Medium-hard wire ropes, Bowden cables, cable and round steel

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 822413 Knipex 95 61 190 Wire rope cutter Suitable for (cable stripping) Single/multi-core aluminium and copper cables, Medium w

Description

For medium-hard wire ropes up to Ø 6 mm, for example Bowden Cables, but also suitable for cable and round steel. With opening spring and locking device. Blades also induction-hardened. Special cutting geometry prevents a splitting of the wire rope For hard wire ropes, also suitable for cable and round steel With Crimp functions e.g. for bicycle-Bowden sleeve end-caps and Bowden cable end sleeves. Precise, easy-moving screw joint. Opening spring lying in the joint, secure and protected against loss; With locking device. Chrome-vanadium high speed steel, forged, oil-hardened multi-level

This text is machine translated.

Features

For hard wire ropes, also suitable for cable and round steel
With crimping function e.g. for bicycle-Bowden sleeve end-caps
Precise, easy-moving screw joint
Opening spring lying in the joint, secure and protected against loss; with safety catch
Special cutting geometry prevents a splitting of the wire rope
Special tool steel in special quality, forged, oil-hardened
Polished head, grip covered with plastic.
