Monacor SP-4/60PRO 4 inch 10.16 cm Subwoofer 30 W 8 Ω
EAN:
Part number:
Item no:
Number
Total (€ 22.68 / piece)
€ 22.68
plus VAT.
Technical specifications
- Impedance (Z): 8 Ohm
- Resonant frequency (fs): 92 Hz
- Max. Frequency range: f 3-10000 Hz
- Maximum load capacity 60 WMAX
- Nominal load (P): 30WRMS
- Avg. Sound pressure (1W/m): 90 dB
- Suspension compliance (cms): 0.47 mm/N
- Moved mass (MMS): 6.3 g
- Mechanical quality (Qms): 5.35
- Electrical quality (Qes): 0.67
- Total quality (Qts): 0.60
- Equivalent volume (Vas): 3.04 l
- Dc resistance (Re): 6.76Ohm
- Power factor (BxL): 5.85 Tm
- Schwingspulenind. (Le): 0.3 mH
- Voice coil diameter: 25 mm
- Kapton voice coil carrier:
- Linear excursion (Xmax): +/-2.3 mm
- Eff. Cone area (sd): 68 cm2
- Magnet weight: -
- Weight: 0.9 kg
- Product type
Subwoofer
- Speaker size (inch)
4 inch
- Speaker size (cm)
10.16 cm
- RMS capacity
30 W
- Max. load
60 W
- Min. frequency
92 Hz
- Max. frequency
10000 Hz
- Impedance
8 Ω
- Sound pressure
90 dB
- Recess diameter
10.3 cm
- Recess depth
11.8 cm
- Weight
900 g
- Frequency range
92 Hz - 10000 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1332605 Monacor SP-4/60PRO 4 inch 10.16 cm Subwoofer 30 W 8 Ω
Description
Hobby HiFi 01/2013
"Inspiring low distortion values for a very clean middle playback."
Hi Fi-Selbstbau 07/2012
"Value for money, inconspicuous, but very good, is it 100% on the point in a description for the mid-range chassis SP -4/60 PRO from IMG Stage Line is looking for.
With head is also often further than with material battles. . .
The Army from monacor already know why the SP -4/60 PRO in the dopplepack in the PA-combination L-ray/1000.
We had always wondered about that one there only a 10cm chassis used - now we know why: the one can also with the "hammer on the head", without that he stutters device. Everything correctly.
This text is machine translated.
"Inspiring low distortion values for a very clean middle playback."
Hi Fi-Selbstbau 07/2012
"Value for money, inconspicuous, but very good, is it 100% on the point in a description for the mid-range chassis SP -4/60 PRO from IMG Stage Line is looking for.
With head is also often further than with material battles. . .
The Army from monacor already know why the SP -4/60 PRO in the dopplepack in the PA-combination L-ray/1000.
We had always wondered about that one there only a 10cm chassis used - now we know why: the one can also with the "hammer on the head", without that he stutters device. Everything correctly.
This text is machine translated.
Features
- PA mid-range
- 10-cm-PA mid-range (4)
- Mid-range from the L-RAY/1000
- Very linear frequency response and wide range
- Excellent sound and dynamic properties
- By for a mid-range system high linear displacement very deep at bass systems ankoppelbar
- Perfectly suited for small-PAs, speaker lines and can also be used as a hi-mid-woofer
