Name: Phoenix Contact 1700282 Spring-loaded terminal 1.00 mm² Number of pins 4 Green 50 pc(s)
Brand: Phoenix Contact
SKU: 717373
Price: 95.99 EUR
Availability: InStock

Green and orange two-row, pluggable printed circuit board terminals, seven poles on the left, two poles on the right. Suitable for electrical connections.

Image similar

Product type

Spring-loaded terminal

3.81 mm

Pins per row

Number of pins

Connection

Spring-loaded terminal

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 16 Nov

681 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 50 pc(s))

Set(s)

Total (€ 1.92 / piece)

€ 95.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block FFKDSA1/H-3,81- 4

Content 50 pc(s)

Technical specifications

Type: FFKDSA1/H-3,81- 4

Product type: Spring-loaded terminal

Features: + push-in spring bracket
+ actuator

CS: 3.81 mm

No. of rows: 1

Pins per row: 4

Number of pins: 4

Series: FFKDS(A)/H

Stripping length (max.): 10.00 mm

Connection: Spring-loaded terminal
Print

Nominal current: 12 A

Nominal current - rounded value: 12 A

Cross section (flexible) (max.): 1.00 mm²

Cross section (inflexible) (max.): 1.00 mm²

AWG (min.): 26

Connector orientation: Parallel (to the PCB)

AWG max.: 18

Contact material: Tin plated

Enclosure material: Polyamide

Factory colour: Green

Wire protection: Yes

Actuation direction: Parallel (to the PCB)

Manufacturer part #: 1700282

Industrial packaging: Yes

Content: 50 pc(s)

Nominal voltage: 160 V

Width: 16.40 mm

Height: 15.24 mm

Length: 13.60 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 717373 Phoenix Contact 1700282 Spring-loaded terminal 1.00 mm² Number of pins 4 Green 50 pc(s)

User & Safety Instructions

User & Safety Instructions 717373 Phoenix Contact 1700282 Spring-loaded terminal 1.00 mm² Number of pins 4 Green 50 pc(s)

Description

PCB terminal block, Nominal current: 12 A, Nom. voltage: 160 V, Pitch: 3.81 mm, Number of positions: 4, Connection method: Spring-cage conn., Mounting: Soldering, Conductor/PCB connection direction: 0 °
