Buy Telegärtner 100023013 Telegärtner 100023013 N/A 100023013 Plug, straight Pins: 8P8C Light grey 1 pc(s) 100023013 Plug, s

A grey Ethernet cable with a specialised protective plug, suitable for industrial applications.

Image similar

Technical drawing of a valve with dimensions: Height 59.5 mm, Width 42.7 mm. Shows side and front view with detailed line configurations.

1/2

Image similar

Product type

RJ45 connector

Connector type

Plug, straight

Specification

CAT 6A

Connector standard

RJ45

Type

100023013

Datasheet (PDF)

Fast track dispatch on Wed, 23 Sep

15 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 10.92 / piece)

€ 21.00

-48 %

€ 10.92

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

Telegärtner 100023013 N/A 100023013 Plug, straight Pins: 8P8C Light grey 1 pc(s)

Our service for you

Technical specifications

Type: 100023013

Product type: RJ45 connector

Connector type: Plug, straight

: CAT 6A

Connector standard: RJ45

AWG max.: 24

AWG (min.): 27

Connection: Cut & Clip

Factory colour: Light grey

Content: 1 pc(s)

Contact material: Phosphorus bronze

RoHS-compliant: Yes

Seal type: Snap-in

Standards: IEC 61076-3-106

: IP67 (when connected)

Material (details): PA6 UL94 V0

Type: Straight

Nominal current (details): 1.0 A at 50°C

: 24-27

Pins: 8P8C

Mating cycles: min. 750

Temperature range: -40°C to + 70 °C

UKCA: not relevant

Variants(All information is without VAT, plus shipping costs)

Connector standard

Connector type

Specification

Telegärtner 100023013 Telegärtner 100023013 N/A 100023013 Plug, straight Pins: 8P8C Light grey 1 pc(s) 100023013 Plug, straight Pins: 8P8C Light grey 1 pc(s)

Item no:1179992

This article

RJ45

Plug, straight

CAT 6A

Telegärtner 100022949 Telegärtner 100022949 N/A 100022949 Socket, straight Pins: 8P8C Light grey 1 pc(s) 100022949 Socket, straight Pins: 8P8C Light grey 1 pc(s)

Item no:1179993

RJ45

Socket, straight

CAT 6

Telegärtner 100022951 Telegärtner 100022951 N/A 100022951 Connector, mount Light grey 1 pc(s) 100022951 Connector, mount Light grey 1 pc(s)

Item no:1179994

USB 2.0

Connector, mount

Telegärtner 100007422 Telegärtner 100007422 N/A 100007422 Connector, mount Pins: 8P8C No. of pins (RJ) 8P8C Metal 1 pc(s) 100007422 Connector, mount Pins: 8P8C No. of pins (RJ) 8P8C Metal 1 pc(s)

Item no:1179997

RJ45

Connector, mount

CAT 6

Telegärtner 100007423 Telegärtner 100007423 N/A 100007423 RJ45 socket, mount Pins: 8P8C No. of pins (RJ) 8P8C Metal 1 pc(s) 100007423 RJ45 socket, mount Pins: 8P8C No. of pins (RJ) 8P8C Metal 1 pc(s)

Item no:1179998

RJ45

RJ45 socket, mount

CAT 6A

Telegärtner 100007387 Telegärtner 100007387 N/A 100007387 Plug, straight No. of pins (RJ) 8P8C Metal 1 pc(s) 100007387 Plug, straight No. of pins (RJ) 8P8C Metal 1 pc(s)

Item no:1550111

RJ45

Plug, straight

CAT 6A

Telegärtner 100007381 Telegärtner 100007381 N/A 100007381 RJ45 sleeve inset No. of pins (RJ) 8P8C Metal 1 pc(s) 100007381 RJ45 sleeve inset No. of pins (RJ) 8P8C Metal 1 pc(s)

Item no:1550134

RJ45

RJ45 sleeve inset

CAT 6A

Telegärtner 100007390 Telegärtner 100007390 N/A 100007390 RJ45 connector enclosure Metal 1 pc(s) 100007390 RJ45 connector enclosure Metal 1 pc(s)

Item no:1550206

RJ45

RJ45 connector enclosure

CAT 6A

Telegärtner 100007379 Telegärtner 100007379 N/A 100007379 Socket, straight Metal 1 pc(s) 100007379 Socket, straight Metal 1 pc(s)

Item no:1550226

RJ45

Socket, straight

CAT 6A
